• Model NO.：GD-2801H
• Test Standard：ASTM D5
• Power Supply：AC(220+-10%)V, 50Hz
• Power Consumption：200W
• Measurement Range：0 Penetration~600 Penetrations
• Resolution：0.1 Penetration
• Timing Range：0s~60 S, and The Error Is Less Than +-0.1 S
• Data Saved：50 Groups
• Standard Needle：50mm, 2.5+-0.05 G
• Sample Container：55*H35
• Standard Weight：50g
• Lifting Device：Automatic Lifting
• Transport Package：Plywood
• Trademark：GOLD
• Origin：Chongqing China
• HS Code：9031809090
• Production Capacity：100 PCS , Month

Basic Info.

Model NO. GD-2801H Test Standard ASTM D5 Power Supply AC(220+-10%)V, 50Hz Power Consumption 200W Measurement Range 0 Penetration~600 Penetrations Resolution 0.1 Penetration Timing Range 0s~60 S, and The Error Is Less Than +-0.1 S Data Saved 50 Groups Standard Needle 50mm, 2.5+-0.05 G Sample Container 55*H35 Standard Weight 50g Lifting Device Automatic Lifting Transport Package Plywood Trademark GOLD Origin Chongqing China HS Code 9031809090 Production Capacity 100 PCS / Month

Product Description

Automatic ASTM D5 Penetrometer for consistency test



Introduction:

The Automatic ASTM D5 Penetrometer is designed and made as per the standards GB/T4509 Standard Test Method for Penetration of Bitumen, T0604 Bitumen Penetration Test in the standard JTG E20-2011 Specifications and Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering and ASTM D5.
The Automatic ASTM D5 Penetrometer is suitable to determine the penetration of highway bitumen, modified asphalt, as well as liquid petroleum asphalt or residue of emulsified asphalt after evaporation.


Features:

1. Measurement accuracy of the instrument can reach to 0.6 penetrations.
2. New type penetrometer detection unit, and the test repeatability is stable.
3. It adopts high resolution capacitance touch screen, the information can be clearly displayed.  Special "Computer Drawing Software + Data Accurate Reading
4. Technology", it can automatically draw and print the nomogram of asphalt penetration relationship.
5. It adopts new type lifting device.


Parameters:

1. Power supply: AC(220±10%)V, 50Hz
2. Power consumption: 200W
3. Measurement range: 0 penetration~600 penetrations
4. Resolution: 0.1 penetration
5. Timing range: 0s~60 s, and the error is less than ±0.1 s
6. Data saved: 50 groups
7. Standard needle: 50mm,2.5±0.05 g
8. Sample container:  Φ55×H35
9. Standard weight: 50g 10. Lifting device: automatic lifting 11. Dimension:260mm×400mm×600mm 12. Net weight: 15kg
