Nbs Smoke Density Chamber, ASTM E662, ISO 5659
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Standard：ASTM E 662, F814, BS6401, ISO 5659, Nes 711
- Size：1, 600(W)* 820(D) * 2, 150(H)
- Weight：350kg
- Power Supply：220 V AC, 60 Hz, 15 a
- Exhust：50 L,S
- Display：17" Touch Screen
Base Info
- Model NO.：GD-ISO5659
- Warranty：1 Year
- Transport Package：Plywood Case
- Trademark：Gold
- Origin：China
- HS Code：9031809090
- Production Capacity：10 Sets,Month
Description
Features:
• Integrated body and 19" analysis rack (Saving space)
• 17" touch screen panel type PC for the whole control and automatic testing
• Air cylinder type movement to load sample or automatically open the up/down vent(highly resistant to pollution from test)
• Coating of the test chamber convenient in cleaning and resistant to chemicals
• Lock designed to close the chamber door at a time
• Indication of transmission rate and smoke density with improved accuracy
• Chamber preheat system to facilitate test with more accuracy
• Safety blow-out panel system to protect user when pressure is sharply increased during test
• Port, heated filter, and heated line to measure toxic gases
• Manometer gauge with increased accuracy by using the MFC(Mass Flow Controller) and DPT(Differential Pressure Transducer) enabling auto leakage test
• Portable water cooling system without need for waterworks and plumbing when using the Heat Fluxmeter (for ISO 5659)
• Load cell with increased accuracy to measure mass loss rate in ISO 5659 test
• SB 2005 DAQ(Data Acquisition) Program to control the use of touch screen panel PC
Test Result:
• Laboratory Information
• User's CI
• Specimen Conditions
• Time from start of test, t(s)
• Transmission(%) and specific optical density, Ds
• Maximum Ds and time to maximum Ds
• Correction Ds
• Current range setting and filter position
• Current mass(g) for ISO 5659
