• Model NO.：XHJS401A
• Trademark：XZH TEST
• Origin：China Xi′an
• HS Code：854320100
• Production Capacity：100 Pieces ,Year
• Package size per unit product：45.00cm * 35.00cm * 20.00cm
• Gross weight per unit product：40.000kg

Basic Info.

Model NO. XHJS401A Trademark XZH TEST Origin China Xi′an HS Code 854320100 Production Capacity 100 Pieces /Year

Packaging & Delivery

Package size per unit product 45.00cm * 35.00cm * 20.00cm Gross weight per unit product 40.000kg

Product Description





Product description

At present, the lightning arrester monitors have popularized in various large and small substations in China, and their own operating conditions will directly affect the safety of the power system. The lightning arrester's action and leakage current are usually monitored by the lightning arrester monitor. Due to poor sealing, the monitor may enter moisture or moisture during running, causing internal components to rust, or other causes of the monitor counter not functioning properly, and the leakage current indication is not allowed. Therefore, the "Procedures" stipulate that the lightninh arrester monitor should be inspected once a year. This instrument is our best choice.



Main features

1. The monitor count can be checked on-power/off-power

2. The accuracy of the monitor ammeter can be verified on-power/off-power

3. True RMS measurement, good stability

4. The inter-frequency output is strong in anti-interference ability under the online state

5. Standard sine wave output, the verification result is completely same

6. Built-in battery measurement, it's very convenient for on-site using



Main Technical Parameters

Power supply: built-in battery 4Ah 12V

Output frequency: 55Hz

Output current: 5mA/10mA (cancustomized)

Resolution: 0.001mA

Current accuracy: 0.5%±3 words

Inrush current: 50A ~ 100A (instant)

Impact voltage: DC 1000V

Action count: 1 ~ 2s / times

Action number: cyclical measurement
