PLC Control Partial Discharge Test System for transformer, mutual inductor and lightning arresters

HV Hipot Electric Co., Ltd.
  • Type：Universal Testing Machine
  • Accuracy Grade：1
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control

Base Info

  • Model NO.：GDYT-10,100
  • Weight：0-100Kg
  • Power Source：AC220V
  • Rated Capacity：10kVA
  • Output Voltage：100kv customized
  • Output Current：100mA customized
  • Input Voltage：200V
  • Input Current：50A
  • Short-Circuit Impedance：≤ 8%
  • Warranty：1 year
  • PD value：≤10PC @ 100% rated voltage
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030899090
  • Production Capacity：2000PCS,Year

Description

Power supply220V±22V,50HZRated Capacity10kVAOutput Voltage100kVOutput current100mA   Input Voltage200V, current: 50Ashort-circuit impedance≤ 8%Operation time60mins@100% rated voltage and current.
Continuous working@ 50% rated voltage and current.Wave form distortion rate<5% when voltage regulator input voltage distortion rate <3%, within 10-100% rated voltage rangePD value≤10pC @ 100% rated voltage
≤5pC @ 80% rated voltage
