• Model NO.：GDOT-80C
• Weight：0-100Kg
• Power Source：AC220V
• Output Voltage：0-80kV
• Power Input：AC220V± 10%, 50Hz±1Hz
• Capacity：1.5kVA;
• Accuracy：±3%
• Voltage Distortion Rate：≤3%
• Voltage Increasing Speed：2.0kV,S, 3.5kV,S
• Standing Time：15mins, Adjustable
• Transport Package：Carton or Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030899090
• Production Capacity：2000PCS,Year

Basic Info.

Model NO. GDOT-80C Weight 0-100Kg Power Source AC220V Output Voltage 0-80kV Power Input AC220V± 10%, 50Hz±1Hz Capacity 1.5kVA; Accuracy ±3% Voltage Distortion Rate ≤3% Voltage Increasing Speed 2.0kV/S, 3.5kV/S Standing Time 15mins, Adjustable Transport Package Carton or Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030899090 Production Capacity 2000PCS/Year

Product Description

I. General information

GDOT Insulation Oil Breaker Tester is fully digital industrial instrument with microcomputer control. It has the features of high accuracy and strong anti-interference ability.

II. Features

LCD screen display.
Single-chip control, easy to control.
Wide range watch dog circuit to avoid system halted.
Unique HV sampling design to make the test data entering into A/D converter directly, to avoid error caused by analog circuit, which will make measurement more accurate.
Automatic completing all test procedures.
1-6 times breakdown voltage value and times will be saved automatically. It will print test results.
With over-voltage, over-current and short circuit protection.
Portable design, easy to move.



III. Specifications

Output voltage: 0-80kV
Power distortion rate: <1%
Voltage increasing speed: 0.5kV/s, 2.0kV/s, 3.0kV/s. Error10%.
Voltage increasing times: 1-6times, optional
Electrode gap: standard 2.5mm
Capacity: 1.5kVA
Power input: AC220V±10%, 50Hz±1Hz
Power: 200W
Working temperature: 0-45°C
Humidity: <85%RH
Dimension: 430*350*370mm
