• Model NO.：GD-8019
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Na
• Item Name：ASTM D381 Petroleum Products Existent Gum Tester
• Test Samples：Fuel, Gasoline and Motor Gasoline
• Sample Quantities：3 Samples
• Temperature Display：Digital Display
• Component：Gum Tester ASTM D381 and a Air Compressor
• Test Method：Jet Evaporation Method
• Heating Method：Oil Bath Heating
• Applicable Standards：ASTM D381
• Power Supply：220V 50Hz
• Warranty：1 Year
• Transport Package：Venner Case
• Specification：68*53*52CM
• Trademark：GOLD
• Origin：Chongqing, China
• HS Code：9031809090
• Production Capacity：100 Set,Month

Basic Info.

Model NO. GD-8019 Loading Method Static Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Na Item Name ASTM D381 Petroleum Products Existent Gum Tester Test Samples Fuel, Gasoline and Motor Gasoline Sample Quantities 3 Samples Temperature Display Digital Display Component Gum Tester ASTM D381 and a Air Compressor Test Method Jet Evaporation Method Heating Method Oil Bath Heating Applicable Standards ASTM D381 Power Supply 220V 50Hz Warranty 1 Year Transport Package Venner Case Specification 68*53*52CM Trademark GOLD Origin Chongqing, China HS Code 9031809090 Production Capacity 100 Set/Month

Product Description

GD-8019 ASTM D381 Petroleum Products Existent Gum Tester, Existent Gum Evaporating Bath

Introduction:

1. GD-8019 ASTM D381 Petroleum Products Existent Gum Tester, Existent Gum Evaporating Bath is designed and made as per standards GB/T 8019 Standard test method for gum content in fuels by jet evaporation and ASTM D381. Standard test method for gum content in fuels by jet evaporation.
2. GD-8019 ASTM D381 Petroleum Products Existent Gum Tester, Existent Gum Evaporating Bath is suitable to determine the existent gum content of Aviation Gasoline and Motor Gasoline (Not suitable to determine the existent gum content of aviation turbine fuel).


Features:

1. GD-8019 ASTM D381 Petroleum Products Existent Gum Tester, Existent Gum Evaporating Bath equips a specially designed heating bath.The gas circuit is designed reasonably and the effect of evaporation is good.
2. The material of working bench is stainless steel. It has 3 sample holes. Each jet flow can be adjusted and controlled by an independent flowmeter. It can do 3 determinations at the same time.
3. GD-8019 ASTM D381 Petroleum Products Existent Gum Tester, Existent Gum Evaporating Bath is desktop structure. Simple design and easy to operate. It equips an air compressor to make it meet requirements of standard.


Specifications:

No.	Item Name	GD-8019 ASTM D381 Petroleum Products Existent Gum Tester, Existent Gum Evaporating Bath
1	Power supply	AC(220±10%)V,50Hz,2500W
2	Dimension of evaporation bath	φ260mm×130mm
3	Sample positions	3 positions
4	Dimension of sample positions	φ51mm×70mm
5	Working temperature	(160~165)°C
6	Temperature control	Automatic
7	Temperature display	Digital display
8	Flow display	Displayed by a ball float type flowmeter
9	Working pressure of air reducing valve	0.035MPa
10	Air source	External connection,over (1000±150)mL/s
11	Dimension	590mm×480mm×340mm(Thermometer holder is not included)

Note: A air compressor is equipped.
