Computer Control Automatic Astmd 2272 Lubricating Oils Oxidation Stability Tester

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Max Diameter of Workpiece：<500mm
  • Mass Scope of Workpiece：<900kg
  • Type：Universal Testing Machine
  • Maxcapacity：<1000KN
  • Accuracy Grade：0.5
  • Load Way：Electronic Load

Base Info

  • Model NO.：GD-0193
  • Loading Method：Static Load
  • Display：Digital
  • Control：Manual Control
  • Weight：0-100Kg
  • Power Source：AC220V
  • Oil Cylinder Position：Na
  • Item Name：Astmd2272 Lubricating Oil Oxidation Stability Test
  • Application：Determine The Oxidation Stability of Steam Turbine
  • Function：Determine New Mineral Insulating Oil Containing 2
  • Reference Standard：ASTM D2272
  • Temperature Control Range：Room Temperature - 200.0 C
  • Features：Automatically Determine Pressure, Record Data, Cal
  • Test Method：Rotating Pressure Vessel Method
  • Sample Quantity：2PCS
  • Power Supply：220V 50Hz
  • Warranty：1 Year
  • Transport Package：Venner Case
  • Specification：89*70*112CM
  • Trademark：GOLD
  • Origin：Chongqing, China
  • HS Code：9031809090
  • Production Capacity：100 Set,Month

Description

Item NameGD-0193 Computer Control Automatic ASTMD 2272 Lubricating Oils Oxidation Stability Tester1Power supplyAC220V±10%2Heating tube power2500W3Range for pressure sensor(0~1.6)MPa,accuracy:±2‰4Temperature controll range for oil bathRoom temperature~200.0ºC, continuously adjustable.150.0ºC in common use5Temperature control accuracy±0.1ºC6Test sampleTwo-bomb design, can do two samples at one time. Convenient to do parallel test7Rotation speed(100±5)r/min8Included angle between oxygen bomb and water level30°9Volume of oil bath30L10Dimension550mm*800mm*1000mm11Net weightAbout 45Kg Packing List:
Product NameUnitQuantity
GD-0193 GD-0193 Computer Control Automatic ASTMD 2272 Lubricating Oils Oxidation Stability TesterSet1
PCSet1
Oxygen Bomb AssemblySet2
Glass test cupPC2
PTFE coverPC2
Seal ring of oxygen bombPC2
Test cooper wirem6
Spanner of oxygen bombPC1
Connection pipes and connector of oxygen cylinderRoot1
USB cableRoot1
Stem mercury thermometer 100°C~150°C/0.1°C PC1

Our Services

Pre-sale Service:

  • Inquiry will be replied within 24 hours.
  • Welcome to visit our factory.
  • Technical datas and operation manual sent for evaluation.


Computer Control Automatic Astmd 2272 Lubricating Oils Oxidation Stability Tester

After-sale Service:

  • Training how to instal the machine, training how to use the machine at our factory;
  • Engineers available to service machinery overseas at customers' cost;


Computer Control Automatic Astmd 2272 Lubricating Oils Oxidation Stability Tester
