Htxz-264kVA/22kv Made in China AC Conversion Frequency Cable Resonant Tester Hipot Resonant Test System for Withstand Voltage Test System
Wuhan UHV Power Technology Co., Ltd.- After-sales Service：Life-Long Maintaince
- Warranty：1 Year
- Connectors：USB
- Test Mode：One-sided Test
- Usage：Coaxial Cable Tester, Digital Cable Tester, Hv Cable Tester
- Test Region：Forming Cable
Base Info
- Model NO.：HTXZ
- Cable Type：Hv Cable
- Power：Electricity
- Certification：CE, RoHS, ISO
- Customized：Customized
- Color：Red
- Lead Time：Usually 20-30 Days
- Shipment：by Sea, Denpend on Customer′s Choice
- Online Teachment：Available
- Comply Standard：GB 50150-2016, Dl,T 849.6-2016, Dl,T 474.4-2018
- Application：Cable, Hydraulic Generator, Main Transformer, Bus
- Structures：Power Source, Excitation Transformer, Reactors
- Working Frequency：30-300Hz
- Device Output Waveform：Sine Wave
- Waveform Distortion Rate：Output Voltage Waveform Distortion Rate <1%
- Working Time：Continuous 60min Is Allowed Under Rated Load; Over
- Temperature Rise：<65K After Continuous Operation Under Rated Load
- The Quality Factor：Q>30(F=45Hz)
- Protection Function：Over Current, Over Voltage and Flashover Protectio
- Accuracy of Measurement：Effective Value of The System Is 1.5
- Environment Temperature：-100-50 Celsius Degree
- Transport Package：Wooden Case
- Specification：see details
- Trademark：HV TEST
- Origin：China
- HS Code：9030899090
- Production Capacity：60 Sets Per Month
Description
