• Display：Digital
• Control：Computer Control
• Weight：>2000Kg
• Power Source：AC380V
• Oil Cylinder Position：No
• Usage：Transformer Test
• Transport Package：20gp Container
• Specification：20GP container
• Origin：Shanghai

Basic Info.

Display Digital Control Computer Control Weight >2000Kg Power Source AC380V Oil Cylinder Position No Usage Transformer Test Transport Package 20gp Container Specification 20GP container Origin Shanghai

Product Description



1.Power frequency test transformer

Now we have two types of test transformer:
YD-Relative humidity of HV component(Non condensing)
Voltage 5kV ~ 500kV/Capacity 5kVA ~ 1000kVA

YDT-Series modular type(epoxy barrel) test transformer
Voltage 10kV ~ 1500kV/capacity 1.0kVA ~ 1500kVA

2.Environment

• Maximum Altitude 1000 m
• Altitude increases 100m, and rated voltage lowers 1%
• Operation temperature of HV component 3ºC~ + 45ºC
• Relative humidity of HV component(Non condensing) 95 %
• Operation temperature of electrical component 10ºC~ + 45ºC
• Relative humidity of electrical components (Non condensing) 80 %
• Storage and transport temperature 20ºC~ + 60ºC
• Anti-seismic 8 grade
• Grounding resistance <1.0
• No dust

3.Main technical parameter

• Rated voltage:1.0kV ~ 1500kV(and above)
• Rated capacity: 1.0kVA ~ 1500kVA(and above)
• Noise:65dB(2m away from equipment)
• PD level: 80% of rated voltage, PD2pC(or smaller as users required)
• Operation duty : at rated capacity, 1 hour on, 1hour off, 3-6 times one day; Continuously working at 50% of rated capacity(Or other duration according to test requirement)
