• Model NO.：GD-R2065
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-R2065 HS Code 9031809090 Production Capacity 100sets/Month

Product Description

Automatic ASTM D3241 JFTOT Jet Fuel Thermal Oxidation Stability Tester



Introduction:
1. The JFTOT Jet Fuel Thermal Oxidation Stability Tester is designed according to the requirements of ASTM-D3241 and GB/T9169 methods, and adopts a number of advanced technologies to realize the automation of the instrument testing process. The touch-operated industrial computer can monitor the working state and working interface of the instrument at any time; It has self-diagnostic fault alarm protection system; computer running program designed according to ASTM-D3241 method ensures the correct and complete test process; the instrument has the function of historical data storage and test report printing ; the instrument also has the function of custom setting system parameters. It fully meet the needs of special tests for production and scientific research.

2. The JFTOT Jet Fuel Thermal Oxidation Stability Tester also has the advantages of small size, light weight, less sample usage, short test period and high analytical precision. The test method was to pass a 600 ml sample through a heated test tube at a flow rate of 3 ML / min at 200-370 ° C and return it to the upper portion of the cylinder through a test filter. The filter is a porous precision oil filter that captures products from fuel degradation during testing. The degree of metamorphic deposition is represented by the magnitude of the differential pressure before and after the filter, and the magnitude of the differential pressure and the color deposited on the surface of the test tube are used as criteria for evaluating the dynamic thermal oxidative stability.

3. The JFTOT Jet Fuel Thermal Oxidation Stability Tester can be divided into two major parts; the analysis system and the control system.


Main Features:
1. Large-screen full-touch LCD display for intuitive operation and display of the entire process of the test. The interface is simple, and the experiment mode can be directly selected, which is convenient and reliable to use, and the test process and measurement data are all clear at a glance.
2. The main electrical components of the control and measurement departments are imported components to ensure the reliability and stability of the instrument. The instrument is compact, compact and beautiful in appearance.
3. The instrument has self-diagnosis and alarm functions.
4. The instrument is equipped with a standard stylus printer, which can list the test results one by one.


Parameters:
1. The new Falex heating tube comes from Falex, the world's oldest supplier of standard tribological test pieces.
2. Falex's new heating tube passes the extremely stringent test specified by ASTM D.02.J0 Subcommittee
3. Test temperature: 100ºC~380ºC±1ºC
4. Pressure difference: 0 ~ 340mmHg
5. Pressure system: 500 psi±50 psi
6. Test sample volume: 600ml
7. Cooling water flow: 38±8L/H Cooling water pressure: 0.1~0.4Mpa
8. Differential pressure measurement accuracy: 0.3
9. Differential pressure display resolution: 0.1mmHg
10. Fuel oil flow: 20 drops / 9±1 second
11. Display mode: touch screen
12. Control method: microcomputer
13. Working power supply: AC220V 50HZ
14. Ambient temperature: 10 ~ 40ºC
15. Relative humidity of air: <85%
