Partial Discharge Measuring Instrument
Xi'an Xu&Hui Electromechanical Technology Co., Ltd.- After-sales Service：Warranty Certificate
- Warranty：Warranty Certificate
- Transport Package：Wooden
- Trademark：XZH TEST
- Origin：China Xi′an
Base Info
- Model NO.：XHJF801D
- HS Code：854320100
- Production Capacity：100 Pieces ,Year
Description
Technical characteristics
Number of interfaces
2 electric signal interfaces, 1 external synchronization interface
Sampling accuracy
12bit
Range changing
60dB,50dB,40dB,30dB,20dB,10dB,0dB,-10dB, totally 8 types
Range of measurement frequency
80k-200kHz,40k-300kHz
Nonlinear error in the range
5%
Measurement range
0.1pC~100000pC
Sensibility
0.1pC
Capacity range of the measured product
6pF~250µF
Frequency range of test power
50~400Hz
Display
Display screen
7'' TFT true color touchable LCD screen
Resolution
800×480
Storage
Physical storage
256MB DDR2, RAM
SD card storage
Standard 4G card, can be upgraded to 32G, using to save test records and test data.
Interface
RS232
Use of synchronizing the transformation interface with PC.
USB
Use of external mouse, keyboard and other USB devices.
Power mode
AC220V
Electric signal interface
2 BNC interfaces, use of signal input.
SMA interface
External synchronization interface.
SD card interface
Can insert the SD card of maximum 32G.
Network interface
Expandable
Landing button
External landing
General instruction
CPU
Basic frequency 533MHz
System
WINCE6.0
Operating environment temperature
-20ºC to 45ºC
Storage environment temperature
-20ºC to 60ºC
Size
Length×width×height: 350mm × 245mm × 175mm
Weight
5.8kg
