GDHG-206 CT/PT Transformer current and voltage On-site Calibrator

HV Hipot Electric Co., Ltd.
  • After-sales Service：yes
  • Warranty：1 year
  • Max Diameter of Workpiece：3000mm
  • Mass Scope of Workpiece：<900kg
  • Accuracy Grade：1
  • Load Way：Electronic Load

Base Info

  • Model NO.：GDHG-206
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control
  • Power Source：AC220V
  • CT Turns Ratio Range：5A,5A- 25000A,5A (5A,1A- 5000A,1A)
  • PT Turns Ratio Range：Full range measurement ±0.2%
  • Accuracy of PT/CT Error：±0.05%
  • CT Secondary Burden：1-25 ohm ±2%
  • PT Secondary Burden：1VA-500VA ±2%
  • Ratio Error：0.001%-3% (100V)
  • Angle Error：0.00′-50′ (100V)
  • Delivery Time：15-20 days
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan, China
  • HS Code：9030849000
  • Production Capacity：5000 Sets,Year

Description

DC Resistance0.0-0.1ohm ±3%0.1-50 ohm ±1%CT Secondary Burden1 ohm -25ohm ±2%PT Secondary Burden1VA-500VA ±2%Ratio Error0.001%-3% (100V)Angle Error0.00'-50' (100V)Admittance0.1ms-99.9msErrorX= ±(2%×X+2%×Y±2digit), Y= ±(2%×X+2%×Y±2digit)
Different types of CT/PT calibrator are available
GDHG-206 CT/PT Transformer current and voltage On-site Calibrator
GDHG-206 CT/PT Transformer current and voltage On-site Calibrator

GDHG-206 CT/PT Transformer current and voltage On-site Calibrator
GDHG-206 CT/PT Transformer current and voltage On-site Calibrator
