GDTF-200/200 Up to 200kV CVT Injection Test Set

HV Hipot Electric Co., Ltd.
  • After-sales Service：yes
  • Warranty：1 year
  • Type：CVT Test and Calibration
  • Maxcapacity：No
  • Accuracy Grade：0.2
  • Load Way：Electronic Load

Base Info

  • Model NO.：GDTF-200,200
  • Loading Method：Static Load
  • Display：Digital
  • Control：Manual Control
  • Weight：500-1000Kg
  • Power Source：380V or 415V
  • Oil Cylinder Position：No
  • Input Voltage：380V or Other
  • Transport Package：Wooden Case
  • Specification：SGS, ISO
  • Trademark：HVHIPOT
  • Origin：Wuhan, China
  • HS Code：9030899090
  • Production Capacity：700set,Year

Description

Rated capacity200kVARated frequency50HzRated voltage200kVRated current1AAdjustable inductance range330-630HAdjustable gap range0-120mm

Excitation Transformer  GDJL-10kVA/5/10kV
 Rated capacity10kVAInput voltage0-400V, single phase 50HzOutput voltage5kV,10kVTypeDry type transformerWeightapprox. 60kg

Control Unit  GDTF -10kVA
 Rated capacity: 50kVARated voltage: 50kVRated current: 1AInductance: 330-630H (per set, adjustable)Quality factor: Q ≥20 Weight: Approx. 80kg

HV Testing Transformer  YD-10/100
 Input voltage0-400VInput current25AOutput voltage0-100kVOutput current0-100mA
GDTF-200/200  Up to 200kV  CVT Injection Test SetGDTF-200/200  Up to 200kV  CVT Injection Test Set
