GDYD-85D 5kVA 80kV AC Hipot Test Set with oil-immersed transformer
HV Hipot Electric Co., Ltd.- After-sales Service:Yes
- Warranty:1 year
- Max. output voltage:80kV
- Rated Capacity:5kVA
- Max. current:62.5mA
- Display:Digital display
Base Info
- Model NO.:GDYD-85D
- Transport Package:Standard Export Plywood Case
- Specification:ISO
- Trademark:HV HIPOT
- Origin:Wuhan, China
Description
Basic Info.
Model NO. GDYD-85D Transport Package Standard Export Plywood Case Specification ISO Trademark HV HIPOT Origin Wuhan, ChinaProduct Description
GDYD-85D 5kVA 80kV AC Hipot Test Set with oil-immersed transformerI. General information
GDYD series AC hipot testing is the effective and direct way to test insulation strength for electrical equipments,apparatus or machines. It checks dangerous flaws which assure electrical equipment continuous working.
Typical applications include testing of transformers, switchgear, cables, capacitors, aerial motors platforms, hot sticks bucket bricks, vacuum bottles and other related equipment like vacuum interrupters, blankets, ropes, gloves, hydraulics hose, instruments transformers generators.
II. Features
- Digital display meters mounted on the panel.
- Monitoring HV side voltage, HV side current, LV side current and indicator of zero, power, working start, timing.
- Over-current protection, zero-starting protection, sound and light alarm.
- With new type time relay, time range is more wider (1S ~ 99H).
- Using the latest current relay, more accurate and reliable.
- Light weight, small size, easy to move.
III. Specifications
- Control unit specifications
- Power: AC220V, 50Hz
- Capacity: 5kVA
- Output voltage: AC 0-250V
- Rated output current: 25A
- Rated current rectified range: 0-25A
- HV voltmeter range: 0-80kV
- HV ammeter range: 0-62.5mA
- LV ammeter range: 0-25A
- Timing range:1s-99h
- Weight: 19kg
- Dimension: 440mm (L)*340mm (W)*240mm (H)
B. Testing transformer (HV unit) specifications
- LV side voltage (Input voltage): 0-200V
- LV side current (Input current): AC 0-25A
- HV side voltage(Output voltage): AC 0-80kV
- HV side current(Output current): AC 62.5mA
- Capacity: 5kVA
- HV side/LV side turns ratio: 400:1
- Measuring voltage: AC 0-200V
- No-load current: <10%
- Impedance voltage: <10%
- Weight: 120kg
- Dimension: 450mm(L)*330mm(W)*1080mm(H)
C. Working conditions
- Working place: No gas, steam, chemical dust and explosive and corrosive medium which will influence insulation.
- Environment temperature: -20--50ºC
- Environment humidity: ≤85% RH (no condensing)
