SF6 Gas Recycle Machine (GDQH-601)

HV Hipot Electric Co., Ltd.
  • Accuracy Grade：1
  • Load Way：Electronic Load
  • Display：Digital
  • Weight：200KG
  • Power supply：Three phase five line 3Φ 380V zero line a
  • Liquefaction mode：Frozen liquefaction

Base Info

  • Model NO.：GDQH-601
  • Vaporization mode：Electric heating
  • Dry filter regenerative way：Vacuum heating Activate regeneration
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9027809900
  • Production Capacity：2000PCS,Year

Description

Basic Info.

Model NO. GDQH-601 Vaporization mode Electric heating Dry filter regenerative way Vacuum heating Activate regeneration Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9027809900 Production Capacity 2000PCS/Year

Product Description

SF6 Gas Recycle Machine (GDQH-601)

Main Configuration

  1. SF6 compressor (Using halogen SF6 special semi-closed compressor, brand Copeland)
  2. Gas displacement: 0-13m3/h
  3. Max. Discharge pressure: 2.5Mpa
  4. Min. Suction pressure: 50Kpa
  5. Max. Suction pressure: 0.35-0.8Mpa
  6. Power: 2.2kW
  7. Power supply: 380V, 50Hz
  8. Vacuum pump, using twin-stage direct connection vacuum pump.
  9. Vacuum pump is air-cooled type, continuous running
  10. Vacuuming rate: 40m3/h
  11. Limit Vacuum degree: 0.06pa
  12. Power: 1.5kW
  13. SF6 Refrigeration Set, requirement is main engine 1.35kW, 2000kcal/h, R22, 380V, 50Hz
  14. Filtering system (purification system)

It has filter from USA Hankison inside, dry filter (molecular sieve can vacuum and activate and then make recycling treatment),  to remove solid dust, water or decomposition products from the gas.
  1. Valve, DN15--13.5Mpa, special for SF6 gas
  2. High voltage connection tube, 2pcs, connector: inner M27*1.5mm
  3. Cylinder converting connector, one piece
  4. Liquefier, one piece
