• Model NO.：GDYD-1050A
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030332000
• Production Capacity：5000 Pieces,Year

Basic Info.

Model NO. GDYD-1050A Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 5000 Pieces/Year

Product Description

Features

l  Enhanced 320×240 LCD Display(Daylight visible).
2  Simple and easy to operate.
3  On-screen display in testing process.
4  Automated testing support.
5  Automatic analysis function,easy to detect the spark-over, arcing-over faults.
6  Fully System Protection function, avoids Overvoltage, over-current operation.
7  Automatically get the peak voltage, current.
8  Automatically control the voltage back to zero before the next step, to ensure safety.
9  Anti-interference design, can work in harsh electromagnetic environment.
10  Built-in printer, to get testing results automatically.

Technical Specifications


Input	AC 380V±10%
Frequency	50Hz±1
Output	0-100kV, 500mA AC RMS
Rating	100% rated-1 minute, 50%-continuous
Capacity	50kVA
HV source	Insulation gas (gas type testing transformer)
Voltage accuracy	≤1.0% (F.S.)
Current accuracy	≤1.0% (F.S.)
Timing range	0-99H
Metering	Digital display, kV meter: AC 0-100kV, mA meter: AC 0-500mA
Humidity	85%RH
Environmental temperature	-20-50ºC
