• Model NO.：GDOT-100C
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：no
• Model number：GDOT-100C
• Power：Electronic
• Usage：Strength Testing Machine
• Output voltage：100kV
• Capacity：1.5kVA
• Electrode gap：2.5mm
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030899090
• Production Capacity：5000 Pieces,Year

Basic Info.

Model NO. GDOT-100C Weight 0-100Kg Power Source AC220V Oil Cylinder Position no Model number GDOT-100C Power Electronic Usage Strength Testing Machine Output voltage 100kV Capacity 1.5kVA Electrode gap 2.5mm Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030899090 Production Capacity 5000 Pieces/Year

Product Description

Product Description

GDOT Insulation Oil Breakdown Tester Is Fully Digital Industrial Instrument With Microcomputer Control. It Has The Features Of High Accuracy And Strong Anti-Interference Ability.

Features

• Adopts large-capacity single-chip, with reliable performance;
• A wide range of watchdog circuit is set inside the instrument to prevent system failure;
• The oil cup is made of special glass with once-step casting technique to prevent oil leakage and other interference phenomena;
• Unique high-voltage sampling design allows test values to be in the A/D converter directly, which avoids errors caused in the analog circuit, more accurate;
• The instrument has over current, over voltage, short circuit protection and other functions, and has a strong anti-interference ability, good electromagnetic compatibility;
• Portable structure, easy to move, convenient for indoor and outdoor use.

Specifications

Output voltage	0-100kV
Voltage distortion rate	< 1%
Voltage increasing speed	2kV/s, 3kV/s (optional)
Capacity	1.5kVA
Power input	AC220V± 20%, 50Hz±5Hz
Power	<200W
Working temperature	0-40ºC
Humidity	≤85%RH
Dimension	410*390*380mm
