Insulating Rod Leakage Test Set Withstand Voltage Device GDJ-100
HV Hipot Electric Co., Ltd.- Type：Strength Testing Machine
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Control：Manual Control
- Weight：0-100Kg
- Power Source：AC220V
Base Info
- Model NO.：GDJ-100
- Max Voltage：110kv
- Transport Package：Standard Export Box
- Specification：1200*720*1340 mm
- Trademark：HVHIPOT
- Origin：China
Description
-10ºC-40ºC
Humidity
≤90%RH, non-condensing
Continuous running time
Continuous
Stand model
Stand size
Max. Withstand voltage kV
GDJ-50
1000*1000
100kV
GDJ-100
1000*1000
100kV
GDJ-200
1000*2000
300kV
GDJ-300
1000*2000
300kV
GDJ-400
1000*3000
500kV
GDJ-500
1000*3000
500kV
Electrical test requirement of insulating rods
Rated voltage KV | Test distance m | Test voltage KV | Test time min |
10
| 0.4 | 45 | 1 |
35 | 0.6 | 95 | 1 |
66 | 0.7 | 175 | 1 |
110 | 1.0 | 220 | 1 |
220 | 1.8 | 440 | 1 |
330 | 2.8 | 380 | 3 |
500 | 3.7 | 580 | 3 |
750 | 4.7 | 780 | 3 |
