• Model NO.：GD-2134E
• Certification：ISO
• Customized：Non-Customized
• Color：Blue
• Output Frequency：500Hz, 1kHz, 8kHz, 33kHz, 66kHz, and 93kHz
• Output Power：Max.10W
• Output Voltage：Max.200V (AC Peak Value)
• Display：128*64 LCD Display
• Built-in Lithium Battery：Nominal 14.8V, 7ah
• External Power Supply：Rated Voltage DC12V (Car Cigarette Lighter Output
• Charger：AC 100-240V Input, 50,60Hz, Output DC 16.8V, 2A,3A
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：China
• HS Code：9030332000
• Production Capacity：2000PCS,Year

Basic Info.

Model NO. GD-2134E Certification ISO Customized Non-Customized Color Blue Output Frequency 500Hz, 1kHz, 8kHz, 33kHz, 66kHz, and 93kHz Output Power Max.10W Output Voltage Max.200V (AC Peak Value) Display 128*64 LCD Display Built-in Lithium Battery Nominal 14.8V, 7ah External Power Supply Rated Voltage DC12V (Car Cigarette Lighter Output Charger AC 100-240V Input, 50/60Hz, Output DC 16.8V, 2A/3A Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin China HS Code 9030332000 Production Capacity 2000PCS/Year

Product Description

GD-2134E Cable Fault Identifier with Tracing and Depth Locating Function


GD-2134E is a high-performance underground metal pipeline detection system composed of signal transmitters and receivers. It can be used for path detection, pipeline survey and depth measurement of metal pipelines and underground cables. It can carry out uniqueness identification with a variety of selected accessories, as well as pipe insulation damage and the search for some types of cable faults


Features


1. Compass display: intuitively displays the pipeline location and left & right directions.
2. Tracking true and false prompts: current direction measurement, tracking correct error prompts, eliminating line interference (some frequencies).
3. Depth and current measurements, can display the signal strength historical curve.
4. Fully digital high-precision sampling processing: stable and reliable, ultra-high sensitivity, narrow receiving passband, strong anti-interference ability, can fully suppress the power frequency and harmonic interference of adjacent running cables and pipelines.
5. Running cable detection: high-performance transmission clamps, maximum coupling output signal to the running cable.
6. Cable/pipeline identification: Flexible clamps (optional) are easy to use and clearly give identification results; stethoscopes (optional) can be used when it is not convenient to use clamps.
7. Ground fault finding: HV booster (optional) boosts the maximum output voltage to 1000V, uses the A frame (optional) to locate the ground insulation breakage points of the pipeline, no need to adjust zero. The arrow indicates the direction of the fault point.
8. Multiple detection frequencies: active detection and passive detection.
9. A variety of signal output of the transmitter: direct connection output, clamp coupling output, radiation induction.
10. High power output of transmitter, multiple output adjustable, automatic impedance matching and protection.
11. Built-in large capacity lithium ion battery group, it will automatic shutdown undervoltage or long time no operation,
12. Rugged case, light and portable.

Specifications


Transmitter


1. Output modes: direct connection output, radiation induction, clamp coupling output(optional), fault locating HV booster(optional).
2. Output frequency: 640Hz (compound frequency), 1280Hz (compound frequency), 10kHz, 33kHz, 82kHz, 197kHz.
3. Output power: Max.10W, 10 gears adjustable, automatic impedance matching.
4. Direct connection output voltage: maximum 150Vpp.
5. Overload and short circuit protection.
6. Man-machine interface: 320 x240 dot matrix LCD display.
7. Built-in battery: 4 section 18650 lithium ion battery, nominal 7.4V, 6.8Ah.


Receiver


1. Input mode: Built-in receiving coil, flexible clamp-on CTs(optional), Stethoscope(optional), A type fault detection device(optional).
2. Receiving frequency:
   Active detection frequency for Pipes: 640Hz, 1280Hz, 10kHz, 33kHz, 82kHz, 197kHz.
   Power frequency passive detection frequency:50Hz/60Hz and 250Hz/300Hz(user configurable).
   RF passive detection frequency: the center frequency is 10kHz, 33kHz,82kHz respectively.
3. Pipe detection mode: Wide peak method, narrow peak method, sound Valley method.
4. Cable identification mode: flexible clamp-on CTs(optional) automatic identification and current measurement, stethoscope(optional) identification.
5. 320*240 LCD display, shows signal amplitude, left/right direction, correct/false indication, history curve of signal strength, depth, current and result.
6. Built-in battery, 2 section 18650 lithium ion battery, rated 7.4V, 3.4Ah


Others


1. Dimension: Transmitter 280*220*90mm. Receiver 680*277*120mm.
2. Weight: Transmitter 2.3kg. Receiver 2.0kg.
3. Charger: AC100-240V input, 50/60Hz, output DC 8.4V,2A/3A.
4. Working condition: Temperature -10-40ºC, Humidity 5-90% RH, altitude<4500m

Optional accessories (Specify when ordering, unspecified default unselected)


No.	Name	Drawings and instructions
1	Connecting cable for receiver accessories.	Blue 6-core plug
2	Connecting cable for transmitter accessories.	Red 5-core plug
3	Clamp-on CT for transmitter
4	Flexible CT for receiver
5	A frame
6	Fault detection HV booster
7	Miniature stethoscope
8	Long stem stethoscope
9	Detection rod for long stem stethoscope
