• Model NO.：GW-217
• Accuracy Grade：1
• Load Way：Electronic Load
• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：100-500Kg
• Power Source：AC220V
• Oil Cylinder Position：Electric Control
• Packaging：Wooden Case
• Export Markets：Global
• Model No：Gw-220
• Altitude Range：8 Inch(0-6 Inch) Adjustable
• Testing Route：0-200mm
• Shocky Way：Spring Loaded Type 1.7 Kg,mm
• Testing Speed：5-40 C.P.M Adjustable
• Number of Setting Time：1-999999
• Rxterior Size：140*120*250cm
• Power：AC 220V, 50Hz
• Transport Package：Standard Export Safety Packing
• Specification：100~150KG
• Trademark：Great win
• Origin：China
• HS Code：9024800000
• Production Capacity：1000PCS,Month

Basic Info.

Model NO. GW-217 Accuracy Grade 1 Load Way Electronic Load Loading Method Dynamic Load Display Digital Control Manual Control Weight 100-500Kg Power Source AC220V Oil Cylinder Position Electric Control Packaging Wooden Case Export Markets Global Model No Gw-220 Altitude Range 8 Inch(0-6 Inch) Adjustable Testing Route 0-200mm Shocky Way Spring Loaded Type 1.7 Kg/mm Testing Speed 5-40 C.P.M Adjustable Number of Setting Time 1-999999 Rxterior Size 140*120*250cm Power AC 220V, 50Hz Transport Package Standard Export Safety Packing Specification 100~150KG Trademark Great win Origin China HS Code 9024800000 Production Capacity 1000PCS/Month

Product Description

The luggage shock and impact  test machine(GW-217)

Brief introduction:

This machine be used to test the  handle  ,sewing and impact of suitcase .  The test way is to regulation the load of the  tested object,then use 30time/minute and 4 inches of stroke testing 2500 times.then the test result can as a standard to improve the production.

Technical Specifications:

Model	GW-0217 The luggage shock and impact tester
1,The range of altitude:	8 inch(0-6inch)adjustable
2,The shock way:	spring-loaded type 1.79Kg/mm
3,The testing route	0~200mm
4,Testing speed	5~40 C.P.M.adjustable
5,Number of Time setting:	1~999999,
6,Exterior size:	1400×1200×2500
7,The weight of machine:	390Kg
8:Power:	1φ,220V/50Hz



Standard for:
QB/T 2922-2007
  13967709546What about the product quality?
For our products, each instrument must be carried out 100% quality calibration and test when delivery goods. With CE certificate, we are very confident in our products, and we will pack them with safety wooden case to protect the machine when transport oversea.

What about usage of the machine?
We will also give your professional guidance(Product operating manual and video), each products comes with a USB flash drive which have all the details.

What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support, we can help them solve their problem through email, video meeting. We also can provide door to door service, but customer need to bear the travel fees.

What about standards support?
We are strictly following different international standards such as EN, ISO, ASTM, AATC, JIS, GB ect, and had been recognized by SATRA, CSA international standard agency.
