• Model NO.：GW-053B
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Electric Control
• Packaging：Wooden Case
• Export Markets：Global
• Model No：Gw-053b
• Power：AC 220V 50Hz
• Falling Ball Height：500mm
• Steeed Ball Diameter：16+,-0.5 mm
• Instrument Testing Resolution：1,10000 Second
• Test Error：<1%
• Dimension：250*200*650mm
• Transport Package：Wooden Case
• Specification：250*200*650mm
• Trademark：Great Win
• Origin：China
• HS Code：9024800000
• Production Capacity：500 Pieces,Year

Basic Info.

Model NO. GW-053B Loading Method Static Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Electric Control Packaging Wooden Case Export Markets Global Model No Gw-053b Power AC 220V 50Hz Falling Ball Height 500mm Steeed Ball Diameter 16+/-0.5 mm Instrument Testing Resolution 1/10000 Second Test Error <1% Dimension 250*200*650mm Transport Package Wooden Case Specification 250*200*650mm Trademark Great Win Origin China HS Code 9024800000 Production Capacity 500 Pieces/Year

Product Description

   Foam and rubber Resilience Testing Machine /equipment(GW-053B )

Brief introduction:
This tester is the steel ball falling in soft foam plastic or other flexible material sample, measuring instruments, the height of the rebound in the test project is mainly used for the determination of polyester elastic material because of the elastic energy in the coefficient of restitution. By microcomputer and photoelectric technology, electromagnetic control, digital tube display directly back to the weak coefficient values.
Technical  Specifications:

Model	GW-053B Resilience Testing Machine
1.power voltage:	220v 50HZ
2.Falling ball height :	500 mm
3.Steed ball diameter :	16±0.5mm
4.Instrument testing resolution:	1/10000 second
5.The coefficient of restitution measurement range :	25%-80%
6.Test error	< 1%
7. Instrument dimensions(W*D*H ):	250*200*650

Standard for:
GB-6670-2008 "The determination of the soft foam resilience can"
American D3574 "soft foam adhesive and the model of polyurethane foam plastic"
900

What about the product quality?
For our products, each instrument must be carried out 100% quality calibration and test when delivery goods. With CE certificate, we are very confident in our products, and we will pack them with safety wooden case to protect the machine when transport oversea.

What about usage of the machine?
We will also give your professional guidance(Product operating manual and video), each products comes with a USB flash drive which have all the details.

What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support, we can help them solve their problem through email, video meeting. We also can provide door to door service, but customer need to bear the travel fees.

What about standards support?
We are strictly following different international standards such as EN, ISO, ASTM, AATC, JIS, GB ect, and had been recognized by SATRA, CSA international standard agency.
