• Model NO.：SXCF
• Control：Computer Control
• Power Source：380V,220V110V at Cutomized
• Nominal Voltage：200kv or at Customized
• Rated Energy：10kj or at Customized
• Impulse Capacitance：0.5UF or at Customized
• Each Stage：100kv 0.25UF or at Customized
• Transport Package：Plywood Cases
• Trademark：Sansion Power
• Origin：Wuhan, China
• HS Code：9030339000
• Production Capacity：100 Sets, Year

Basic Info.

Model NO. SXCF Control Computer Control Power Source 380V/220V110V at Cutomized Nominal Voltage 200kv or at Customized Rated Energy 10kj or at Customized Impulse Capacitance 0.5UF or at Customized Each Stage 100kv 0.25UF or at Customized Transport Package Plywood Cases Trademark Sansion Power Origin Wuhan, China HS Code 9030339000 Production Capacity 100 Sets/ Year

Product Description

Impulse Voltage Test System Generator High Voltage 200 KV / 10 KJ

General Information:
This impulse test system is used for carrying out standard lightning impulse voltage full wave and operation wave tests on HV apparatus such as power capacitors, clearance, bushings, power transformers and CT/PT at 10kV or below.

Main Parameters for System
Nominal voltage: ±200kV

Impulse capacitance: 0.5µF

Number of stages: 2

Rated stage voltage: ±100kV

Rated energy: 10kJ

Rated stage capacitance: 1µF(each impulse capacitor 1µF at 100kV, total 2pcs)

Impulse voltage waveform: generated when load capacitance is 300-3000pF.T1=1.2µs±30%, T2=50µs±20%, standard lightning impulse voltage full waveform of peak voltage deviation≤3%;
Standard operation waveform 250±20%/2500±60%. These 2 Impulse voltage waveform parameters and error are accorded with national requirements of GB311.1and GB16927.1 standard and IEC standard.

Voltage utilization factor: Standard lightning impulse voltage waveform ≥90% when load capacitance is below 1000pF, standard operation impulse voltage waveform≥80% when load capacitance is below 2000pF. Standard operation impulse voltage waveform ≥70%.

Locking range: level voltage is within the range of 20%-100% rated voltage, positive and negative locking range no less than 25%.

Out-of-control rate of synchronous discharge: <5%

Min. output voltage: ≥±20% of rated voltage.

Instability of discharge voltage: <±1.0%

Continuous time: Above 2/3 of rated voltage, continuous working when charge and discharge once every 120s. Below 2/3 of rated voltage, continuous working when charge and discharge once every 60s.

Above information for reference using, please contact us for further technical details.

Impulse Voltage Generator

More details please contact Sansion Power by email for further information.
