Made in China 2019 35kV High Voltage Detector
HV Hipot Electric Co., Ltd.- Rated voltage：35kV
- Starting voltage：5.25~14kV
- Electrical test response distance：<15mm
- Leakage current：<30uA
- Test sound intensity：>75dB
- DC voltage test：35kV
Base Info
- Model NO.：GD-3,35kV
- Power frequency AC hipot test：150kV
- In phase interference：<14kV
- Working voltage：6V
- Delivery time：20 working days
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- Production Capacity：5000 Sets,Year
Description
Voltage levelRemark 3kV 6kV 10kV 27.5kV 35kV 66kV 110kV 220kV 330kV 500kV Starting voltage kV 0.45-1.2 0.9-2.4 1.5-4.0 4.1-11 5.25-14 9.9-26 16.5-44 33-88 49-132 75~200 Contact Electrical test response distance
mm
<5
<10
<15
<15
<60
<60
<100
<100
<150
<500Qualified Leakage current UA <30 <30 <30 <30 <30 <30 <30 <30 <30 <30 Qualified Test sound intensity
dB
>75
>75
>75
>75
>75
>75
>75
>75
>75
>75The background noise of 50dB, clear sound DC voltage test
kV
3
6
10
27.5
35
66
110
220
330
500DC voltage test, do not have electric display Electro optic intensity IX 53600 53600 53600 53600 53600 53600 53600 53600 53600 53600 Qualified
Anti arc test
kV
3.6
7.2
12
33
42
79
130
260
400
800When the strongest pull arc occurs, lasts for 1 minutes as qualified.
mm
<5
<10
<15
<15
<60
<60
<100
<100
<150
<500
dB
>75
>75
>75
>75
>75
>75
>75
>75
>75
>75
kV
3
6
10
27.5
35
66
110
220
330
500
Anti arc test
kV
3.6
7.2
12
33
42
79
130
260
400
800
