• Model NO.：GDOT-80A
• Capacity：1.5kVA
• Accuracy：±3%
• Delivery time：15days
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• Production Capacity：10000 Sets,Year

Basic Info.

Model NO. GDOT-80A Capacity 1.5kVA Accuracy ±3% Delivery time 15days Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China Production Capacity 10000 Sets/Year

Product Description

GDOT-80A Insulation Oil Breaker Tester is fully digital industrial instrument with microcomputer control. It has the features of high accuracy and strong anti-interference ability.

Features

* LCD screen display.
* Automatic completing all test procedures.
* 1-6 times breakdown voltage value and times will be saved automatically. It will print test results.
* 100 results can be stored and display current environmental temperature and humidity.
* Single-chip control, easy to control.
* With over-voltage, over-current and limit protection.
* Display temperature and system clock.
* With RS232 port.

Specifications


Output voltage	0-80kV
Voltage distortion rate	<3%
Voltage increasing speed	0.5-3kV/s, adjustable
Standing time	15mins, adjustable
Voltage increasing interval	5mins, adjustable
Voltage increasing times	1-6times, optional
Capacity	1.5kVA
Accuracy	±3%
Power input	AC220V± 10%, 50Hz±1Hz
Power	200W
Working temperature	0-45ºC
Humidity	<75%RH
Dimension	465*385*425mm
