• Model NO.：GDFJ-II
• Storage：100 sets test data
• Printer：built-in printer
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9027100090
• Production Capacity：2000sets,Year

Basic Info.

Model NO. GDFJ-II Storage 100 sets test data Printer built-in printer Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9027100090 Production Capacity 2000sets/Year

Product Description

GDFJ-II SF6 Gas Decomposition Products Analyzer

I. General Information

GDFJ-II SF₆ gas decomposition products analyzer is the device easy to test SF₆ gas decomposition products.In the process of test,connect the device with equipment full of SF₆ gas.When SF₆ gas flow sensors with certain speed,the instrument can measure the content of SF₆ gas main decomposition products. Sensors are special for SF₆ gas,long lifespan design,accurate testing results. Main application include fault location,partial discharge monitoring,gas purification/filter monitoring,fault high voltage contact detection,SF₆ decomposition products detection,switch decomposition products detection.


II. Features

* Long lifespan detecting components.
* High precision,good repeatability.
* Built-in voltage stabilization device and Electronic mass flowmeter.
* Large LCD display
* Light and portable
* AC/DC both ok,built-in rechargeable battery
* Fast response,no preheat waiting.
* Test results is not influenced by environmental temperature.


III. Technical specifications


Measuring range	H2S:0~200µL/L  SO2: 0~200µL/L HF:0~10µL/L  optional CO: 0~1000µL/L  optional
Sensitivity	0.1 µL/L
Sampling flow rate	0.25 L/min±30ml/min
Response time	10~15s
Intake pressure	≤1.0MPa
Sampling	Built-in flow valve, flowmeter
Working temperature	-20ºC~55ºC
Working humidity	≤90%RH
Power	DC built-in rechargeable battery; AC 220V/50Hz
Storage	100 sets test data
Printer	built-in printer
Output interface	USB interface
Dimension	335*290*160mm
Weight	5.7kg
