Good Performance Industrial Drying Ovens for Quality Control Test Chamber

Guangdong Komeg Industrial Co., Ltd.
  • After-sales Service：24 Hours on Line Services
  • Warranty：12 Months
  • Type：Material Testing Machine
  • Weight：100-500Kg
  • Power Source：AC380V
  • Interior Dimensions (D*W*H)：900*1000*800mm

Base Info

  • Model NO.：KOV-720
  • Exterior Dimensions(D*W*H)：1300*1750*1000mm
  • kVA：7.5
  • Accessories：Timer, Adjustable Compartment Plate
  • Safety Devices：NFB, Over Temp. Reley, Fuse
  • Temp. Range：50oc~200oc or 300oc
  • Temp. Constancy：+,-1.0oc
  • Temp. Uniformity：+,-2.0oc(50oc~200oc), +,-3.0oc(50oc~300oc)
  • Heat up Time：50oc~200oc Within 5 Mins
  • Insulation Material：Glass Wool
  • Transport Package：Strong Plywood Case, Meet International Standard
  • Specification：Standard and Customized
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets Per Yesr

Description

Specifications ModelKOV-50KOV-100KOV-200KOV-290KOV-500Interior size (W*H*D)mm400*350*350450*500*450600*600*600600*950*500800*1050*600Exterior size (W*H*D)mm1010*650*7601110*800*11001260*900*1100870*1590*6401160*1760*880Capacity(KVA)3.53.54.54.56PowerAC220V±10% 1Φ 50Hz/60Hz AC 380V±10% 3Φ4wire 50Hz/60HzTemp. range50 ºC~ 200 ºC( 300 ºC)Temp. constancy±1.0 ºCTemp. uniformity±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC)Heat up time50 ºC to 200 ºC within 50 minInterior materialStainless steel plateExterior materialPainted Stainless steel plateInsulation materialGlass woolSafety devicesNo fuse breaker, over temp protection, ceramic fuseAccessoriesRecorder, insolating layerNote: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations Specifications ModelKOV-600KOV-720KOV-1000KOV-1800Interior size (W*H*D)mm1000*1000*600900*1000*8001000*1000*10001600*1400*600Exterior size (W*H*D)mm1360*1720*8801300*1750*10001300*1750*10001600*1940*1200Capacity(KVA)6.57.58.59.5PowerAC 380V±10% 3Φ4wire 50Hz/60HzTemp. range50 ºC~ 200 ºC( 300 ºC)Temp. constancy±1.0 ºCTemp. uniformity±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC)Heat up time50 ºC to 200 ºC within 50 minInterior materialStainless steel plateExterior materialPainted Stainless steel plateInsulation materialGlass woolSafety devicesNo fuse breaker, over temp protection, ceramic fuseAccessoriesRecorder, insolating layerNote: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations
