Tensile Testing Equipment Factory Electronic Single Fiber Strength Tester

Jinan Xinghua Instruments Co., Ltd.
  • After-sales Service：12 Month Excellent After Service
  • Warranty：1 Year
  • Type：Strength Testing Machine
  • Maxcapacity：500cn
  • Accuracy Grade：0.5
  • Load Way：Electronic Load

Base Info

  • Model NO.：XHL-02FE
  • Loading Method：Dynamic Load
  • Display：Needle
  • Control：Computer Control
  • Weight：0-100Kg
  • Power Source：AC220V
  • Transport Package：Plywood Case for Export
  • Specification：ISO 11566, ISO 5709, JIS K1474, JIS R7601, JIS K14
  • Trademark：XHINSTRUMENTS
  • Origin：China
  • HS Code：9024800000
  • Production Capacity：5000 PCS, Year

Description

Range

0-500cN

Force measurement accuracy

<±0.5%

Gauge length

5-60mm (random setting

Max Stoke

120mm (when gauge length 10mm)

Extension measurement error

≤0.05mm

Test speed

3-200mm/min

Pretension setting range

0.00cN-99.99cN

Pretension resolution

0.01CN

Working pressure

0.4-0.6Mpa

Dimension

400mm×290mm×460mm

Net weight

25Kgs

Power supply

AC 220V±10% 50Hz



Tensile Testing Equipment Factory Electronic Single Fiber Strength TesterTensile Testing Equipment Factory Electronic Single Fiber Strength Tester

1. How About Machines Calibration?
Answer: All machines is calibrated well in house before it is out of factory, XH Instruments  will provide you calibration report, if you need calibration certificate from third party, such as ISO 17025 certificate, we also can provide you with extra charge.
2. What about delivery way and delivery item?
Answer: Courier Express  Delivery, Sea  Delivery,  Air Delivery.
EXW Works, FOB, C&F, CIF, ClP, CPT, FCA, DDU.
3. How can I pay you?
Answer:Bank TT, Western Union, L/C, Paypal.
4. How about you after service?
Answer: XH Instruments will give a feedback within 24 hours.Warranty Period is 12 Months.
For problem caused by product quality within warranty period,XH Instruments will provide product maintenance, technical support, freight out and home as well as spare parts free of charge.
Problem not caused by product quality within warranty period or maintenance beyond warranty period is only charged for replaced parts. However, freight charges home and out are at customer' side (only the replaced part is charged if transportation of instrument is unnecessary).
