Test Instrument

Home > Product > Test Machine

Heat Shrinkage Tester Thermal Shrinkage Tester ASTM D 4974 for Yarn and Cord Thermal Shrinkage

Jinan Xinghua Instruments Co., Ltd.
  • After-sales Service：12 Month Excellent After Service
  • Warranty：1 Year
  • Max Diameter of Workpiece：ASTM D4974-02,GB,T 9102-2003,GB,T 9101-2002,GB,T 1
  • Mass Scope of Workpiece：280c
  • Type：Shrinkage Test
  • Loading Method：Dynamic Load

Base Info

  • Model NO.：XHF-53
  • Display：Digital
  • Control：Touch Screen
  • Weight：0-100Kg
  • Power Source：AC220V
  • Transport Package：Plywood Case
  • Specification：520mm*375mm*510mm
  • Trademark：XHINSTRUMENTS
  • Origin：China
  • HS Code：9024800000
  • Production Capacity：5000 PCS, Year

Description

Heating range

Room temp. to 250C

Measurement length

250+/-1mm

Temperature control accuracy

+/-1C

Shrinkage accuracy

0.1%

Timer range

0-999s

Shrinkage force range

0-25N

Shrinkage force accuracy

0.1N

Power Supply

110/220V±10%, 50/60Hz

Dimension

520×375×510mm

Weight

20Kgs


Heat Shrinkage Tester Thermal Shrinkage Tester ASTM D 4974 for Yarn and Cord Thermal ShrinkageHeat Shrinkage Tester Thermal Shrinkage Tester ASTM D 4974 for Yarn and Cord Thermal Shrinkage

1. How About Machines Calibration?
Answer: All machines is calibrated well in house before it is out of factory, XH Instruments  will provide you calibration report, if you need calibration certificate from third party, such as ISO 17025 certificate, we also can provide you with extra charge.
2. What about delivery way and delivery item?
Answer: Courier Express  Delivery, Sea  Delivery,  Air Delivery.
EXW Works, FOB, C&F, CIF, ClP, CPT, FCA, DDU.
3. How can I pay you?
Answer:Bank TT, Western Union, L/C, Paypal.
4. How about you after service?
Answer: XH Instruments will give a feedback within 24 hours.Warranty Period is 12 Months.
For problem caused by product quality within warranty period,XH Instruments will provide product maintenance, technical support, freight out and home as well as spare parts free of charge.
Problem not caused by product quality within warranty period or maintenance beyond warranty period is only charged for replaced parts. However, freight charges home and out are at customer' side (only the replaced part is charged if transportation of instrument is unnecessary).
