• Model NO.：HD-F766
• Power Source：AC380V
• Design Criteria：ASTM F1566; En1957
• Warranty：One Year
• Delivery Time：20 Days After Receive The Deposit
• Maximum Size of Mattress：2.2m*2.2m
• Test Speed：0-20r,Min
• Machine Size (L*W*H)：About 3500*3200*2200mm
• Power：Three-Phase Four-Wire AC 380V 6A
• Accessories：One Hexagonal and Cylinder Wood Barrel Each
• Model：HD-F766
• Cylinder Wood Barrel：140kg, Length 1000mm
• Transport Package：Strong Wooden Case
• Specification：ASTM F1566; En1975
• Trademark：Haida
• Origin：Dongguan, China
• Production Capacity：150 Sets Per Month

Basic Info.

Model NO. HD-F766 Power Source AC380V Design Criteria ASTM F1566; En1957 Warranty One Year Delivery Time 20 Days After Receive The Deposit Maximum Size of Mattress 2.2m*2.2m Test Speed 0-20r/Min Machine Size (L*W*H) About 3500*3200*2200mm Power Three-Phase Four-Wire AC 380V 6A Accessories One Hexagonal and Cylinder Wood Barrel Each Model HD-F766 Cylinder Wood Barrel 140kg, Length 1000mm Transport Package Strong Wooden Case Specification ASTM F1566; En1975 Trademark Haida Origin Dongguan, China Production Capacity 150 Sets Per Month

Product Description

                                                      Automatic Cornell Mattress Durability Tester

Mattress Roller Durability Tester, Using a horizontal hexagonal wooden drum roll or cylinder (both ends of the diameter of 250 mm, the middle part of the 300 mm, rolling back and forth on the mattress, simulate human motion to assess the durability of the mattress.

Test standard: ASTM F1566, EN1957, QB1952

The main components

1. Motor: Taiwan's Teco Motor with reducer of Italy
2. Speed adjustment: Taiwan's "Ed Force" drive
3. Guide bearing: Import from Japan.
4. Rack: Aluminum body and steel
5. Control elements: Imported.

Main technical parameters:

Test purpose: Using a horizontal hexagonal wooden drum roll or cylinder (both ends of the diameter of 250 mm, the middle part of the 300 mm, rolling back and forth on the mattress, simulate human motion to assess the durability of the mattress. )

The main components:
1. Motor: Taiwan's Teco Motor with reducer of Italy.
2. Speed adjustment: Taiwan's "ED Force" drive
3. Guide bearing: Import from Japan.
4. Rack: Aluminum body and steel
5. Control elements: Imported.

Model	HD -F766  Mattress Roller Durability Tester
Hexagonal wood barrel	240±10Lb(109±4.5kg)  Length 36±3in(915±75mm)
Cylinder wood barrel	140kg, length 1000mm
Maximum size of mattress	2.2m×2.2m
Test speed	0-20r/min
Machine size (L×W×H)	about 3500×3200×2200mm
Power	three-phase four-wire AC 380V 6A
Accessories	One Hexagonal and Cylinder wood barrel each

(The table parameters for the company Standard Model parameters, we support customer customization parameters)





The introduction of Haida
Haida products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and are applicable to all scientific research units, quality inspection institutions and academic fields. Our products meet UL, ASTM, JIS, GB,SO, TAPPI, EN, DIN, BS and other domestic and international standards.


If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.
1. Pre-service
    24 Hours online service for your consult.
    Help choose right model,and a series  of service,person,advise. main web site:http://haidaequipment.en.made-in-china.com
2. Middle service
    --Give you best offer
    --Provide discount for many sets order
    --Do customer's request:
    --Choose payment term you convienent.
    --Promptly production and delivery,inform you in time.
    --Can provide invoice value as you like to decrease your tax.
3. After sale service
   --1 year warranty service and all life maintenance.
   --Technical Egineer are avalible for oversea trainning.
   --Free change for some parts
   --Remote control technical consult
   --Free installation DVD
   --Maintenance plan
4,Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.
5,Good Packaging:
Good Packaging:  Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
