• Model NO.：22-T0030,F
• HS Code：90248000
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. 22-T0030/F HS Code 90248000 Production Capacity 50000PCS/Year

Product Description

Manual and Motor Operated Liquid Limit Device

Disc Type Liquid Limit Device



1.hand operated or motorized device,

2.comprising carriage and cam mechanism,brass bowl,drop counter and base with setting gauge.



Specifications



Manual/Hand operated Liquid Limit Device contains a brass pan, which is used to accommodate soil specimens, a base made from fine vulcanite, an impacting device, that is to say, a cam, which is used to set the distance between the pan and the base at 10 mm, a calculator and a groove handler. It is used to determine the liquid limit of the soil, to classify the soil, to provide soil consistency and plastic index needed in design and construction.



Feature:

1.Electric motor as power

2.Infall frequency of the disc: 120 strikes/min

3.Embedded a strike counter

4.The operation is referred to ASTMD318, The Standard Method of Soil Liquid Limit test.
