• Model NO.：GD-2801C
• Optional Cone：1,2 Scalecone, 1,4scalecone
• Warranty：1 Year
• Transport Package：Plywood
• Origin：Made in China
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-2801C Optional Cone 1/2 Scalecone, 1/4scalecone Warranty 1 Year Transport Package Plywood Origin Made in China HS Code 9031809090 Production Capacity 100sets/Month

Product Description

GD-2801C Adhesive Glue / Lubricating Grease Testing Penetrometer


Introduction:

1. The penetrometer is applied to petroleum products and for consistency tests on a wide range of food products, cosmetics, pastes and other solid to semisolid products.
2. Cone penetration is considered the most important of the laboratory-performed tests. While this ASTM test method provides a measure of grease consistency or stiffness, it is not well-suited for used grease, as it requires a large sample, which precludes its use for in-service testing.
3. The cone penetration method employs a weighted cone that is dropped into a fixed-size volume of grease for a defined time period. The depth that the cone is able to penetrate the grease is used to rate the grease's consistency with a scale developed by the National Lubricating Grease Institute (NLGI). This test utilizes three different cup and cone sizes.
4. The degree to which a highly viscous or creamy, pasty, semi-solid sample resists deformation by an applied force and the measure of consistency is called penetration.
To determine the consistency of grease for example, a penetration measurement is taken by allowing a cone assembly of a given weight to sink into the grease for a determined amount of time at a determined temperature. The depth to which tho cone sinks into the grease is the penetration. The deeper the cone sinks the softer the material is.


Features:

1. It adopts digital display to show the penetration number.Easy to observe.
2. Six grade softening control.High timing control accuracy.
3. The needle holder can be adjusted roughly and finely. It is convenient to adjust and exact to aim.
4. Equipped with grease masher and constant temperature bath. The temperature in bath can be controlled automatically.Multipurpose and high cost performance.


Parameters:

1. Measurement range:(0~600)penetration scale
2. Timing controller: 5s, 8s, 10s, 12s, 30s sand 60s, bias within±0.1s
3. Resolution: 0.01mm
4. Penetration accuracy: ±1penetration
5. Heater power: 200W;
6. Temperature control accuracy: 25±0.1ºC (Note:The ambient temperature shall not exceed 20 ºC)
7. Temperature control mode: High accuracy digital temperature controller
8. Constant temperature bath: Hard glass bath
9. Stirring:automatically stirred by a magnetic stirrer
10. Standard needle: 2.5±0.05g
11. Standard cone: 102.5±0.05g
12. Needle holder:It can be adjusted roughly and finely.Convenient toad just and exact to aim the sample.
13. Others: Equipped with a cold light source and a magnifier; Convenient for operation and observation.
14. Optional cones: 1/2 scalecone, 1/4 scalecone
