Automatic Transformer Voltage Ratio and Current Ratio Tester, Single or Three Phase Transformer Turns Ratio TTR Tester
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Function：Voltage Ratio,Turns Ratio,Polarity Test
- Test Sample：Transformer,CT PT
- Test Standards：IEC60044,IEC76-1
- Display：Digital Display
- Ratio Measurement Range：1-10000
- Group Measurement：1-12
Base Info
- Model NO.：GDBC-901
- Test Voltage：0~80V, Frequency 50Hz
- Power Supply：AC220V ± 10%, 50Hz,60Hz
- Transport Package：Plywood Case for Transformer TTR Tester
- Specification：22KG
- Trademark：GOLD
- Origin：Chongqing, China
- HS Code：9030849000
- Production Capacity：500 Pieces,Month
Description
2000-10000 ± 0.5%RDG
Benefits
The test power supply is generated by the internal power amplifier of the tester, and the waveform distortion rate is less than 0.5% and is not affected by the quality of power supply.
Automatic voltage regulation, with automatic protection functions such as transformer reverse connection, over-current, etc., to avoid damage to the instrument due to incorrect operation.
It can be used for power transformer, CT and PT ratio detection.
Convenient standard transformation ratio setting template, don't need to manually calculate the standard transformation ratio value.
GDBC-901 is very light, only 20KG. It's easy to carry. It's suitable for field test.
