Test Instrument

Home > Product > Test Machine

50ton Digital Display Electronic Universal Testing Tester (WDS-500)

Jinan Kason Testing Equipment Co., Ltd.
  • After-sales Service：24 Hours Technical Supply
  • Warranty：12 Months
  • Max Diameter of Workpiece：<500mm
  • Mass Scope of Workpiece：<900kg
  • Type：Universal Testing Machine
  • Maxcapacity：<1000KN

Base Info

  • Model NO.：WDS-500
  • Accuracy Grade：1
  • Load Way：Electronic Load
  • Loading Method：Static Load
  • Display：Digital
  • Control：Manual Control
  • Weight：>2000Kg
  • Power Source：AC220V
  • Max Load：500kn,600kn
  • Accuracy：1 Class
  • Fixtures：Hydraulic Control
  • Load Resolution：1,300000
  • Rang of Deformation：4%-100%
  • Resolution of Deformation：0.04um
  • Transport Package：Standard Export Packing
  • Specification：1360*1000*2830mm
  • Trademark：HST
  • Origin：China
  • HS Code：9024101000
  • Production Capacity：800 Sets Per Month

Description

Four-column floor or desk model,
(upper is compression and lower is tensile)CoverAll aluminum alloyControl methodComputer controlLoad accuracyClass 1Class 0.5Class 1Class 0.5Load range2%~100%F·S0.2%~100%F·S2%~100%F·S0.2%~100%F·SLoad resolution1/300000Rang of deformation4%-100%FSResolution of deformation0.04umAccuracy of displacementWithin±0.5%of indicating loadResolution of displacement0.01mmTest speed(mm/min)0.05-200 stepless arbitrary settingTensile space(mm)700(can be customized) Compression space(mm)700(can be customized) Test width(mm)760(can be customized)
