• Model NO.：GDOT-3B
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Top
• Output voltage：0-100kV optional
• Power distortion rate：<3%
• Voltage increasing speed：0.5~5kV,s adjustable
• Voltage accuracy：2%* reading + 2 digital
• Transport Package：Standard Export Wooden Box
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan, China
• Production Capacity：5000sets,Year

Basic Info.

Model NO. GDOT-3B Weight 0-100Kg Power Source AC220V Oil Cylinder Position Top Output voltage 0-100kV optional Power distortion rate <3% Voltage increasing speed 0.5~5kV/s adjustable Voltage accuracy 2%* reading + 2 digital Transport Package Standard Export Wooden Box Specification ISO, SGS Trademark HV Hipot Origin Wuhan, China Production Capacity 5000sets/Year

Product Description

GDOT-3B Oil Dielectric Strength Tester 100kV

GDOT-3B 100kV 3 Cups Insulation Oil Breakdown Voltage Tester is fully digital industrial instrument with microcomputer control. It has the features of high accuracy and strong anti-interference ability.

Standards

IEC 156:1995 Insulating liquids- Determination of the breakdown voltage at power frequency

Features


1. LCD screen display.
2. Single-chip control, automatic completing all test procedures, automatic boost, hold, stirring, static, calculate, print etc.
3. The operation of this instrument is simple, the operator only needs to make simple settings, and the instrument will automatically complete the test of 1-3 oil samples according to the settings. For each oil sample, the breakdown voltage value and number of cycles are automatically stored. After the test is completed, the thermal printer can print out the breakdown voltage value and average value of each oil sample.
4. Power-down hold, can store 100 experimental results, and can display the current ambient temperature and humidity.
5. It adopts single-chip microcomputer control for uniform speed boost, and the voltage frequency is accurate to 50HZ, making the whole process easy to control.
6. With over-voltage, over-current, limit and other protection to ensure the safety of operators.
7. With temperature measurement display function and system clock display.
8. Standard RS232 interface, can communicate with computer.

Specifications


Output voltage	0-100kV optional
Power distortion rate	<3%
Voltage increasing speed	0.5~5kV/s adjustable
Voltage accuracy	2%* reading + 2 digital
Display	Large LCD screen
Electrode gap	standard 2.5mm
Boost times	1~10 times
Static time	15 min (adjustable)
Boost interval	5 minutes (adjustable)
Booster Capacity	1.5kVA
Power input	AC220V± 10%, 50Hz±1Hz
Power	200W
Working temperature	0-45ºC
Humidity	<75%RH
Dimension	585mm*390mm*410mm
Weight	38kg
