• Model NO.：SXJB
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030899090
• Production Capacity：100 Units

AC power source:






 Amplitude range:      6×(0-30A)
Precision:0.2%6 phase current paralleled max. output:: 180APhase current long term allowable working value: 10APower:  450VA/phase6 phase paralleled max. power: 1000VA6 phase paralleled allowable max. output duty: 10sFrequency range:0--1000Hz
Accuracy:0.001HzHarmonic order: 2-20 times
Phase position: 0--360°; Precision:0.1°DC voltage source:
 Amplitude:30A/phase
Power: 300VA/phase; Accuracy: 0.2%AC voltage source:




 Amplitude range :6 ×(0--125V);  Precision: 0.2%Line voltage range: 0--250VPhase voltage/Line voltage output power: 80VA/100VAFrequency range: 0--1000Hz; Precision: 0.001HzHarmonic order:  2-20 timesDC voltage source:


 Phase voltage output amplitude:0--±150V;   Precision:0.2%Line voltage output amplitude:0--±300V; Phase voltage/Line voltage output power:90VA/180VASwitching value terminal::





 Switching value input terminal: 8 pairsIdle contact: 1--20mA,24V inner sourcePotential switching:0--6VDC is low level
15--250VDCis high levelSwitching value output terminal: 4 pairsIdle contact, interrupting capacity:110V/2A,220V/1ATime measuring range:Range: 1ms~9999s;    Precision: 0.1msPower supply:AC220V±10%, 50Hz  10A
Warranty: One year quality guarantee after shipment.


More information, please kindly contact with us, we can recommend the suitable test set according your requirements and give you the best quotation. Thank you!
