• Model NO.：GD-2132
• Power Source：AC220V
• Tracing and locating distance：local cable 3km, other cable up to 20km
• Detection cable depth：<3m.
• Warranty：1 year
• Transport Package：Standard Export Wooden Box
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan, China
• Production Capacity：5000set,Year

Basic Info.

Model NO. GD-2132 Power Source AC220V Tracing and locating distance local cable 3km, other cable up to 20km Detection cable depth <3m. Warranty 1 year Transport Package Standard Export Wooden Box Specification ISO, SGS Trademark HV Hipot Origin Wuhan, China Production Capacity 5000set/Year

Product Description

GD-2132 Cable Tracing and Depth Locating Device


It includes transmitter, receiver, inductive probe, potential type detection frame. It is suitable to test all kinds of power cable with metallic conductor.
Its main function is locating poor insulation point, detecting circuit and depth of power cable.


Features

1. High sensitivity
2. Low static drift
3. High accuracy of locating
4. Anti-interference
5. LCD screen to show signal and status
6. Built-in rechargeable Li-battery.

Specifications

Tracing and locating distance: local cable 3km, other cable up to 20km

1. Fault impedance resistance:0-5MΩ
2. Locating accuracy: ≤±10cm.
3. Detection cable depth: <3m.
