41kg

Advantages

We have 2 modes:

1) After the boost to the set value, if it doesn't breakdown within one minute, it will return to 0.
2) After the boost to the set value, if it doesn't breakdown within one minute,It can continue to boost until it breaks down.
These two modes are easy to calibrate and can be used as a withstand voltage tester. Just oil qualified, unnecessary breakdown. Breakdown is a destructive test.


Functions

• Breakdown test of user-defined;

• Proof test;

• IEC60156/IS6792/BS5874 test;

• ASTM D1816 standard test;

• ASTM D877 standard test;

• 5 minutes standard test;

• Manual test;

• Calibration interface for customers;

• Uploading data to PC and making word report automatically;

• Result print;

Features

• LCD screen can display test procedure and test result;

• All the human interaction operations complete by the rotating mouse;

• It is very easy for customers to measure the breakdown voltage of all kinds of oil;

• You can print the test result by the micro printer internal the tester;

• Meanwhile, you can upload the test data to PC from RS232 for data analyzing;

• The special circuit design makes the tester has a good performance at stability and anti-noise;

  Success Case




  20Sets GDYJ-502 Transformer Oil BDV Tester Sold to Bangladesh



  6 Sets GDYJ-502 Transformer Oil BDV Tester Sold to Pakistan


  Screen
