• Model NO.：GD-61034
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Cable Smoke Density Tester
• Item Name：IEC61034 Smoke Density Laboratory of Wire and Cabl
• Application：Measuring The Smoke Density of Cable
• Applicable Standards：IEC 61034 - 1 & 2, BS 6853
• Features：High Accuracy, Stable, Reliable
• Frame Material：Stainless Steel SUS 301
• Frame Dimension：3, 000(W) *3, 000(D)*3, 000(H)
• Size：730*650*1300mm
• Gross Weight：90kg
• Power Supply：220V, 50Hz
• Warranty：1 Year
• Transport Package：Packed in Veneer Case
• Specification：Refer to detailed description
• Trademark：GOLD
• Origin：Chongqing, China
• HS Code：9031809090
• Production Capacity：10 Sets, Month

Basic Info.

Model NO. GD-61034 Loading Method Static Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Cable Smoke Density Tester Item Name IEC61034 Smoke Density Laboratory of Wire and Cabl Application Measuring The Smoke Density of Cable Applicable Standards IEC 61034 - 1 & 2, BS 6853 Features High Accuracy, Stable, Reliable Frame Material Stainless Steel SUS 301 Frame Dimension 3, 000(W) *3, 000(D)*3, 000(H) Size 730*650*1300mm Gross Weight 90kg Power Supply 220V, 50Hz Warranty 1 Year Transport Package Packed in Veneer Case Specification Refer to detailed description Trademark GOLD Origin Chongqing, China HS Code 9031809090 Production Capacity 10 Sets/ Month

Product Description

IEC61034 Smoke Density Laboratory Of Wire And Cable

Introduction:

National cable industry to develop low-smoke halogen free cable and materials, such products are required to measure the smoke density of cable;The main principle of smoke density measurement is that in a specific space, cables or materials produce smoke under specific combustion or radiation conditions, and the light beam will decay after passing through the smoke. The light transmittance of the beam is measured and the specific light density and smoke density are calculated.

The wire and cable smoke density tester conforms to GB/T17651.1~2-1998,IEC 61034-1~2:1997 "smoke density test of cables and optical cables burning under certain conditions", which is a test device for measuring the transmittance of smoke released by all insulated metallic conductor cables or optical cables used to transmit electrical energy or signals when burned horizontally under certain conditions.

Standards:

1. IEC 61034 - 1 & 2 - Measurement of Smoke density of cables burning under defined condition
2. BS 6853 - Code of practice for fire precautions in design and construction of passenger carrying trains
3. GB/T 17651.1~2

Features:

1. The box body is composed of a cubic shell with length, width and height of 3000mm±30mm. The internal material of the box body is SUS 304 stainless steel, filled with calcium silicate fireproof material, and the external material is iron, treated with plastic spray

2. All internal fixtures are made of stainless steel;Aesthetic corrosion resistance

3. The total air vent area is 50cm2±10cm2, which is always open during the test;Baffle height is 1000mm

4. Equipped with wire and cable test stand and weight as per standard requirements

5. The door of the test box is equipped with glass observation Windows on opposite sides, and is installed with sealed and transparent Windows, which can transmit light from the horizontal optical measurement system.Height 2150mm±100mm above ground

6. The light source of the photocell is placed at the center of each window of the two walls, without physical contact

7. Specially designed wind duct and custom calibration device to assist the measurement of wind speed and wind pipes and related institutions for calibrating the smoke density test system of fan air volume

Specifications:

No.	Item Name	IEC61034 Smoke Density Laboratory Of Wire And Cable
1	Frame dimension	3,000(W) × 3,000(D) × 3,000(H)
2	Frame material	Stainless Steel SUS 301
3	Transparent sealed window	100 × 100 mm
4	Foundation Fixed	Fixture unit
5	Light Source Power	DC12V, 100W
6	Light Source Focus Angle	48˚ - 4.5˚
7	Light Source Focus Intensity	1:20
8	Photo Cell Diameter	Ø45 mm
9	Photo Cell Cell Type	Selenium Cell
10	Exhaust Blower Fan Flow	7 m3/min ~ 15 m3/min
11	Exhaust Blower Size	246(W) x 220(D) x 205(H) mm
12	Exhaust Blower Material	Stainless Steel (Inner Fan)
13	Exhaust Blower Power	AC220V, 60Hz, φ1, 210W
14	Exhaust Blower Flow Rate(max)	8.0 M3 /min
15	Power Supply	AC220V, 60Hz
16	Torque	normal 300kg.f.cm , max 480 kf.f.cm
17	Rotation Angle	0~90˚ ± 5˚
18	Wind Velocity	≤ 15m/sec
19	Control Rack Dimension	(W) 730 X (D) 650 X (H) 1,400

Company Show:

Pre-sale Service:

• Inquiry will be replied within 24 hours.
• Welcome to visit our factory.
• Technical datas and operation manual sent for evaluation.

After-sale Service:

• Training how to instal the machine, training how to use the machine at our factory;
• Engineers available to service machinery overseas at customers' cost;
