• Model NO.：GD-4929A
• Loading Method：Dropping Point Apparatus
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Na
• Item Name：ASTM D566 Lubricating Grease Dropping Point Tester
• Application：for Dropping Point of Lubricating Grease Testing
• Test Object：Lubricating Grease
• Applicable Standard：ASTM D566, GB,T4929
• Measurement Range：Room Temperature to 300 C
• Features：Oil Bath, Double Tubes Dropping Point Apparatus
• Test Mode：Manual Type Dropping Point Tester
• Packing Size：51*28*56cm
• Warranty Period：1 Year
• Power Supply：220V, 50Hz
• Transport Package：Packed in Veneer Case
• Specification：73*62*49CM
• Trademark：GOLD
• Origin：Chongqing, China
• HS Code：9031809090
• Production Capacity：10000 Sets,Month

Basic Info.

Model NO. GD-4929A Loading Method Dropping Point Apparatus Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Na Item Name ASTM D566 Lubricating Grease Dropping Point Tester Application for Dropping Point of Lubricating Grease Testing Test Object Lubricating Grease Applicable Standard ASTM D566, GB/T4929 Measurement Range Room Temperature to 300 C Features Oil Bath, Double Tubes Dropping Point Apparatus Test Mode Manual Type Dropping Point Tester Packing Size 51*28*56cm Warranty Period 1 Year Power Supply 220V, 50Hz Transport Package Packed in Veneer Case Specification 73*62*49CM Trademark GOLD Origin Chongqing, China HS Code 9031809090 Production Capacity 10000 Sets/Month

Product Description

GD-4929A ASTM D566 Lubricating Grease Dropping Point Apparatus, Lubricant Grease Tester

Introduction:
GD-4929A ASTM D566 Lubricating Grease Dropping Point Apparatus, Lubricant Grease Tester is designed and made as per GB/T 4929 and ASTM D566 Standard;
GD-4929A ASTM D566 Lubricating Grease Dropping Point Apparatus, Lubricant Grease Tester is suitable for Dropping Point of Lubricating Grease testing.


Features:
The oil bath is composed of heat resistant beaker, heater and electric motor. The heating power can be adjusted continuously. The temperature in oil bath is uniform.
Desktop structure. Easy to operate.

Specifications:

No.	Item Name	GD-4929A ASTM D566 Lubricating Grease Dropping Point Apparatus, Lubricant Grease Tester
1	Power supply	AC 220 V±10%, 50 Hz
2	Oil bath	600 ml beaker.
3	Grease cup	Made of chrome plated brass. Its inner diameter is about 9.92 mm and the diameter of orifice for dropping oil is 2.8 mm. The height of the cup is about 12 mm.
4	Test tube	A tube made of heat-resistant glass with rim. Its inner diameter is 11.1 mm to 12.7 mm. There are three indentations at about 19 mm from the bottom, equally spaced on the circumstance. These indentations are used for supporting the grease cup.
5	Thermometer	-5ºC~300 ºC,scale value is 1 ºC. Its total length is 390 mm and the depth immersed is about 76 mm.
6	Heater	Tubular. Power 800 W.
7	Stirring motor	Rotating speed 60 RPM
8	Ambient temperature	-10ºC~+40 ºC
9	Relative humidity	≤85%
10	Maximum power consumption	900 W
11	Dimension	350mm×180mm×410mm

Packing List:

No.	Product name	Unit	Quantity	Remarks
1	GD-4929A ASTM D566 Lubricating Grease Dropping Point Apparatus, Lubricant Grease Tester	Set	1	Including beaker,outer cylinder etc
2	Grease cup	PC	2
3	Tube	PC	2
4	Cork	PC	3
5	Guiding ring	PC	2
6	Thermometer (-5 to 300°C,graduation 1°C)	PC	3	3# for Dropping point
7	Metal bar	PC	1
8	Power wire(250V 6A)	Root	1
9	Thermometer shield ring(1#)	PC	4
10	Fuse 5A(5×20)	PC	2

 Our Services

Pre-sale Service:

• Inquiry will be replied within 24 hours.
• Welcome to visit our factory.
• Technical datas and operation manual sent for evaluation.



After-sale Service:

• Training how to instal the machine, training how to use the machine at our factory;
• Engineers available to service machinery overseas at customers' cost;
