Test Instrument

Cable Outer Sheath Fault Locator

Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
  • Warranty:1 Year
  • Connectors:USB

Base Info

  • Model NO.:XHHD523
  • Test Mode:Saved Test
  • Usage:Network Cable Tester, HDMI Cable Tester, Audio Cable Tester, Coaxial Cable Tester, Digital Cable Tester
  • Test Region:Forming Cable
  • Cable Type:Shielded
  • Power:Electricity
  • Certification:CE
  • Customized:Customized
  • Color:Orange
  • Transport Package:Wooden Box with Foam Inside
  • Specification:350mm*280mm*170mm
  • Trademark:XZH TEST
  • Origin:China Xi′an
  • HS Code:8543201000
  • Production Capacity:2000 Pieces ,Year
  • Package size per unit product:40.00cm * 36.00cm * 20.00cm
  • Gross weight per unit product:40.000kg

Description

Basic Info.

Model NO. XHHD523 Test Mode Saved Test Usage Network Cable Tester, HDMI Cable Tester, Audio Cable Tester, Coaxial Cable Tester, Digital Cable Tester Test Region Forming Cable Cable Type Shielded Power Electricity Certification CE Customized Customized Color Orange Transport Package Wooden Box with Foam Inside Specification 350mm*280mm*170mm Trademark XZH TEST Origin China Xi′an HS Code 8543201000 Production Capacity 2000 Pieces /Year

Packaging & Delivery

Package size per unit product 40.00cm * 36.00cm * 20.00cm Gross weight per unit product 40.000kg

Product Description

Cable outer sheath fault locator

Cable Outer Sheath Fault Locator
Description:

With the city network development, many power supply bureau, construction, and even the design institute are first met 110kV XLPE cable, due to time and lack of experience, resulting in many cable outer sheath can't passed withstand voltage test (10kV/1min). At present, the external protective layer mostly uses HDPE sheath material, passed the DC 25kV/5min withstand voltage test before out of factory, the leakage current is less than dozens of µA. Therefore, after the laying of defects mostly by laying, including external damage during filling and covering process. The defects include termite bites; ground box with water; deterioration of the original defects; grounding wire or part moisture penetration insulation resistance decreased and other reasons, sometimes because the cable buried too deep, or the complexity of the situation around buried cable, so that the positioning is very difficult, some defects can't be solved after many years, with the hidden danger to run.



Feature

Voltage adjustable.

Frequency adjustable.

Over current protection.

Pin-pointing and withstand testing switched by one button, non-blind area. The receiver sensitivity can be adjusted.

Signal frequency adjustable, and zero protection.

The test range without blind area

The receiver sensitivity is adjustable

Signal frequency is adjustable



Technical data

Power:220V(1±10%),50Hz(1±5%)
b)Output voltage:0~10kV(Square wave)
c)output current:200mA
d)Output capacity:2kVA
e)Frequency adjust:Min:0.4Hz,Max:1Hz(range adjustable)

Weight:32kg
