• Model NO.：XHDQ703
• Power：Electricity
• Certification：CE
• Customized：Customized
• Color：Black
• Transport Package：Exported Wooden Case
• Specification：285mm*85mm*56mm
• Trademark：XZH TEST
• Origin：China
• Production Capacity：2000PCS,Year
• Package size per unit product：28.50cm * 8.50cm * 5.60cm
• Gross weight per unit product：1.160kg

Measurement modetesting rangeresolutionAccuracy0.010Ω-0.099Ω 0.001Ω±(1%+0.01Ω)0.10Ω-0.99Ω0.01Ω ±(1%+0.01Ω)1.0Ω-49.9Ω0.1Ω ±(1%+0.1Ω)50.0Ω-99.5Ω0.5Ω±(1.5%+0.5Ω)100Ω-199Ω1Ω±(2%+1Ω) 200Ω-395Ω5Ω±(5%+5Ω) 400-590Ω 10Ω±(10%+10Ω)600Ω-880Ω 20Ω ±(20%+20Ω)900Ω-1200Ω30Ω ±(25%+30Ω)Current0.00mA -9.95mA 0.05mA±(2.5%+1mA)10.0mA -99.0mA 0.1mA±(2.5%+5mA)100mA -300mA1mA±(2.5%+10mA) 0.30A-2.99A0.01A±(2.5%+0.1A)3.0A-9.9A0.1A±(2.5%+0.3A)10.0A-20.0A0.1 A±(2.5%+0.5A)

Technical specifications

Resistance testing range0.01Ω-1200ΩResistance resolution0.001ΩCurrent resolution0.05mAAlarm Threshold Setting Range Resistance1-199ΩCurrent1-499mAPower6VDC(4 PCS of LR6 Alkaline batteries)Working Temperature and Humidity-20ºC-55ºC;10%RH-90%RHDisplay 4 Digits LCD display;  Screen L×W: 47mm×28.5mmClamp Size65mm×32mmClamp Opening Size Extent 32mmWeight1160g (With battery)Dimension285mm×85mm×56mmExplosion-proof mark Exia II BT3 GaProtection levelDouble insulationStructural featuresClamp CTShiftAutomatic gear shiftExternal magnetic, electric field< 40A/m;  < 1v/mSingle measurement time0.5 secResistance measurement frequency> 1 KHzCurrent frequency under test50/60Hz automaticly
