Clamp-on Ground Resistance Tester Singe Clamp Meter

Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
  • Warranty：Warranty Certificate
  • Transport Package：Wooden

Base Info

  • Model NO.：XHDQ703
  • Trademark：XZH TEST
  • Origin：China Xi′an
  • HS Code：854320100
  • Production Capacity：100 Pieces ,Year
  • Package size per unit product：36.00cm * 28.00cm * 20.00cm
  • Gross weight per unit product：30.000kg

Description

Current0.00mA -9.95mA0.05mA±(2.5%+1mA)10.0mA -99.0mA0.1mA±(2.5%+5mA)100mA -300mA1mA±(2.5%+10mA)0.30A-2.99A0.01A±(2.5%+0.1A)3.0A-9.9A0.1A±(2.5%+0.3A)10.0A-20.0A0.1 A±(2.5%+0.5A)

2. Technical specifications

Resistance testing range0.01Ω-1200Ω
Current testing range0.00mA-20.0A
Resistance resolution0.001Ω
Current resolution 0.05mA
Data storage99 sets
Alarm Threshold Setting Range ResistanceResistance:1-199Ω;
Current:1-499mA
Power6VDC(4 PCS of LR6 Alkaline batteries)
Working Temperature and Humidity-20ºC-55ºC;10%RH-90%RH
Display4 Digits LCD display;  Screen L×W: 47mm×28.5mm
Clamp Size65mm×32mm
Clamp Opening SizeExtent 32mm;
Weight1160g (With battery)
Dimension285mm×85mm×56mm
Explosion-proof markExia  BT3 Ga
Protection levelDouble insulation
Structural featuresClamp CT
ShiftAutomatic gear shift
External magnetic, electric field<40A/m;<1V/m
Single measurement time0.5sec
Resistance measurement frequency>1KHz
Current frequency under test50/60Hz automaticly

Packing List
Tester1 unit
Test loop1 unit
6VDC, 4 PCS of AA Alkaline batteries4 pcs
Box1 set
User manual, warranty manual, certificate1 set
