30kV/1.5kVA AC Hipot Test Equipment (Oil Type)

HV Hipot Electric Co., Ltd.
  • Type：Withstand Voltage Test Set
  • Maxcapacity：0-300kv
  • Accuracy Grade：1.5%
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital

Base Info

  • Model NO.：GDYD-M
  • Control：Manual Control
  • Weight：100-500Kg
  • Power Source：AC220V
  • Input：AC220V ± 10%
  • Frequency：50Hz,60Hz ± 1Hz
  • Output：0-30kV, AC RMS
  • HV Source：Oil type testing transformer
  • Output control：Manual control
  • Voltage accuracy：≤1.5% (F.S)
  • Current Accuracy：≤1.5% (F.S)
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030332000
  • Production Capacity：2000PCS,Year

Description

Basic Info.

Model NO. GDYD-M Control Manual Control Weight 100-500Kg Power Source AC220V Input AC220V ± 10% Frequency 50Hz/60Hz ± 1Hz Output 0-30kV, AC RMS HV Source Oil type testing transformer Output control Manual control Voltage accuracy ≤1.5% (F.S) Current Accuracy ≤1.5% (F.S) Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/Year

Product Description

30kV/1.5kVA AC Hipot Test Equipment (Oil Type)

Specifications

Input: AC220V ± 10%
Frequency: 50Hz/60Hz ± 1Hz
Output: 0-30kV, AC RMS
Working Duration: 100%Rated-1minute, 50%-continuous
Capacity: 1.5kVA (based on selectable)
HT Source: Oil type testing transformer
Output control: Manual control
Voltage accuracy: < 1.5% (F.S)
Current Accuracy: < 1.5% (F.S)
Timing range: 0-99H
Metering: Digital display, kV meter: AC 0-30kV, mA meter: AC 0-50mA AC, A meter:0-5A AC
Humidity: 85% RH
Environmental temperature: -20ºC~50ºC
Weight Control unit: about 20kg
Dry testing transformer: about 52kg
