• Model NO.：MD-DJ100-04
• Cylinder：100~500GF Force Adjustable
• Standard Weight：50g , 100g Each Two
• Motor Torque：1.3n.M
• Line Trajectory：Rectangles, Triangles, Lines, Diagonals
• Transport Package：Standard Export Packing
• Specification：W550*D550*H510mm
• Trademark：Minder
• Origin：China
• Production Capacity：50 Pieces, Month

Basic Info.

Model NO. MD-DJ100-04 Cylinder 100~500GF Force Adjustable Standard Weight 50g / 100g Each Two Motor Torque 1.3n.M Line Trajectory Rectangles, Triangles, Lines, Diagonals Transport Package Standard Export Packing Specification W550*D550*H510mm Trademark Minder Origin China Production Capacity 50 Pieces/ Month

Product Description

Products description
This machine is mainly used for mobile phone touch screen, scribing life test, PLC control, touch screen display, with automatic memory, power failure memory, power pressure control, life cycle accumulation, automatic shutdown of the set number of times, etc. Using motion track test, convenient coordinate finding function, the user can take two points on the LCD screen of the mobile phone to draw a line, any three points can generate triangles, four points can generate square or rectangular motion tracks, and can be tested according to the test Mobile phone specifications access motion track for the next call. Moreover, the stepping motor is matched with the linear guide rail and the ball screw for the motion mechanism, which has the characteristics of accurate positioning, high precision and low noise.
Application
Used for mobile phone touch screen click, scribing life test, PLC control, touch screen display, with automatic memory, power failure memory, click power pressure.
Technical parameters

Testing sample	2 pcs
Moving distance	X axis: 90mm; Y axis: 150mm
Movement speed	16 ~ 120 mm / sec
Speed	0-180 times / min
Counter	6-bit count with power-down memory function
Control method	PLC controller and touch screen display
Cylinder	100~500gf force adjustable
Standard weight	50g / 100g each two
Motor torque	1.3N.m
Line trajectory	Rectangles, triangles, lines, diagonals
Dimension	W550*D550*H510mm
Power supply	220V/3A
Weight	35kg

If you need more further details about our products,  please feel free to contact us .
