• Model NO.：GD-508
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Muffle Furnace：ASTM D482 Coal Ash Content Tester
• Test Samples：Gas Turbine Fuels, Crude Oils and Lubricating Oils
• Ash Content Tester：Determine Ash Content in The Petroleum Products
• Reference Standard：ASTM D874
• Heating Range：Ambient Temperature~1000 C
• Compositon：Resistance Furnace, Heating Plate, Ceramic Crucibl
• Price Level：Low Price
• Gross Weight：100kg
• Power Supply：220V 50Hz
• Warranty：1 Year
• Transport Package：Venner Case
• Specification：64*64*88CM
• Trademark：GOLD
• Origin：Chongqing, China
• HS Code：9031809090
• Production Capacity：100 Set,Month

Basic Info.

Model NO. GD-508 Loading Method Static Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Muffle Furnace ASTM D482 Coal Ash Content Tester Test Samples Gas Turbine Fuels, Crude Oils and Lubricating Oils Ash Content Tester Determine Ash Content in The Petroleum Products Reference Standard ASTM D874 Heating Range Ambient Temperature~1000 C Compositon Resistance Furnace, Heating Plate, Ceramic Crucibl Price Level Low Price Gross Weight 100kg Power Supply 220V 50Hz Warranty 1 Year Transport Package Venner Case Specification 64*64*88CM Trademark GOLD Origin Chongqing, China HS Code 9031809090 Production Capacity 100 Set/Month

Product Description

Ash Content Tester ASTM D482 for gas turbine fuels, crude oils and lubricating oils



ASTM D482 - Ash Content Tester

We perform testing refer to ASTM D482 to determine the ash-forming materials in gas turbine fuels, crude oils, lubricating oils, and other petroleum products.
Measuring the ash-forming material present in a petroleum product can provide information as to whether or not the product is suitable for use in a given application. Ash can result from contamination such as oil or water-soluble metallic compounds or from solids such as dirt and rust.
The standard ASTM D482 is applicable to distillate and residual fuels, gas turbine fuels, crude oils, lubricating oils, waxes, and other petroleum products, in which any ash-forming materials present are normally considered to be undesirable impurities or contaminants.


Specifications:


No.	Parts	Box-type Heating furnace
1	Power supply	AC220V±10%, 50 Hz
2	Rated power	2.5 kW
3	Rated temperature	1000ºC
4	Temperature rising time for empty furnace	≤50 min
5	Power consumption for empty furnace	≤800W
6	Heat savings	≤5kW.h
7	Furnace temperature uniformity	≤15ºC
8	Thermocouple	WRN-010
9	Size of furnace chamber	200mm×120mm×80mm
10	Dimension	575mm×3850mm×480mm



No.	Parts	Temperature control stand
1	Rated controllable power	5000W
2	Power supply	AC(220±10%)V, 50Hz
3	Maximum control temperature	1200ºC
4	Temperature controller	DTW2001
5	Thermocouple	WRN-010
6	Dimension	500mm×300mm×235mm



No.	Parts	Electric heating plate
1	Rated power	1500W
2	Power supply	AC (220±10%) V, 50Hz
3	Rated temperature	400ºC
4	Heating power	1~6 grades, continuously adjustable
5	Diameter of heating plate	Φ85mm
6	Dimension	280mm×250mm×90mm


Features:

1. GD-508 ASTM D482 Ash Content Tester is composed of a box-type heating furnace, a temperature control stand and an electric heating plate. It is small size and needs less land.
2. The box-type furnace adopts all-in-one structure. Special fire-resistant material and heating components. The heating time is short and it has a long lifetime.
3. An adjustable LED temperature controller is equipped in the control stand. The overshoot is small and temperature control is stable.
4. The size of heating plate is Φ85mm. Small size and good durability.
