Ce Approved Class 0.02 Current Transformer CT PT Analyzer with Best Price

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Product Name：CT PT Analyzer
  • Application：Test CT PT
  • Test Standards：IEC60044-1, IEC60044-6, IEC60044-2, IEC60044-5, C5
  • Voltage Output：0.1~180V (AC)
  • Current Output：0.001~5A(RMS)
  • Max. Knee Voltage Measurement：45kv

Base Info

  • Model NO.：GDVA-405
  • Current Measurement Range：0~10A
  • Current Measurement Error：<±0.1%+0.01%Fs
  • Power Supply：AC220V±10%, 50,60Hz±10%
  • Voltage Measurement Range：0~200V
  • Transport Package：Plywood Case for CT PT Analyzer
  • Specification：30KG
  • Trademark：GOLD
  • Origin：Chongqing, China
  • HS Code：9030849000
  • Production Capacity：500 Piece,Month

Description

Make evaluation for test results according to selected standards
Make word report for test result
Make word reports one time for multi-group test records on the PC
Calculate the ratio errors and phase angle errors at rated burden and working burden in one time test
Compare excitation curves with saved excitation curves in the same windowMemory capacity>1000 groups test resultsWorking condition temperature-10ºC~50ºC; moist ≤90%
Certificate:
Ce Approved Class 0.02 Current Transformer CT PT Analyzer with Best Price

Exhibition:
Ce Approved Class 0.02 Current Transformer CT PT Analyzer with Best Price
