High Temperature 400 Degree Precision Drying Vacuum Test Equipment
Guangdong Yuanyao Test Equipment Co., Ltd.- Max Diameter of Workpiece：250mm
- Mass Scope of Workpiece：25kg
- Type：Vacuum Drying Oven
- Maxcapacity：N,a
- Accuracy Grade：0.5
- Load Way：N,a
Base Info
- Model NO.：YVO-480
- Loading Method：Static Load
- Display：Digital
- Control：Controller
- Weight：100-500Kg
- Power Source：AC380V
- Oil Cylinder Position：N,a
- Inner Chamber Size Whd：800X1000X600 mm
- External Chamber Size Whd：1100X1720X770mm
- Volume：480 Liters
- Temp. Fluctuation：+,- 0.5 Degree
- Inner Chamber Material：304 Stainless Steel Plate
- External Chamber Material：Cold Rolled Sheet with Powder Coated.
- Temp. Range：Rt+25 &Degree ~+300degree
- Vacuum Pump：Leybold
- Pressure：133PA or -101kpa
- Power：AC 3 Phase 380V 50,60Hz
- Transport Package：Strong Plywood Case
- Specification：CE Certification, ISO
- Trademark：Yuanyao
- Origin：China
- HS Code：8419899090
- Production Capacity：100 Sets,Month
Description
Inner chamber: SUS#304 Stainless steel
External chamber: Cold rolled sheet + powder coated.Temp. Range RT+25 º C ~200º C (400º C) Temp. fluctuation ± 3%º C Temp. resolution 0.1º C; Control Method Micro PID+SSR+Timer Vacuum range 0~ -98KPa/-101KPa Shelf 2 pcs Observation Glass Window When temperature is RT-200º C , with observation glass widow
When temperature is 200º C-500º C , without observation glass widow Power AC 380 V , 3 Phase 5 Lines, 50/60HZ
If you are interested in any item of our company, kindly please send email to us.
Beside vaccum oven, we are also supply temperature and humidity test chamber,Thermal shock chamber, Temperature & humidity Control Host, Ozone test chamber, Salt Spray Tester, Walk In environmental Testing Room, Temperature & humidity & Vibration Combined Testing Chamber, Aging Oven Tester, Rain/Spray Testing Chamber, Burn-in testing equipment, Dust Tester, Steam Aging Tester, Electromagnetic High Frequency Vibration Tester, Tensile Tester, Drop Tester, etc.
