ASTM D2602 D5293 Fully Automatic Cold Cranking Simulator Engine Oil Apparent Viscosity Tester
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- CCS：Low Temperature Dynamic Viscosity Tester
- Dynamic Viscosity Tester：Dynamic Viscosity Tester
- Viscosity Tester：Auto Apparent Viscosity Apparatus of Engine Oils
- Cold Crank Viscometer：Cold Crank Simulator Dynamic Viscosity Tester
- ASTM D5293：ASTM D5293 Apparent Viscosity Tester for Engine Oi
- Apparent Viscometer：Auto Engine Oil Cold Crank Simulator Apparatus
Base Info
- Model NO.：GD-H1089
- Applicable Standards：GB,T6538, ASTM D2602, D5293
- Refrigeration Method：Semiconductor Refrigeration
- Circulation Mode：Cooling Water Circulation
- Temperature Control Mode：Pid Temperature Controller
- Test Temperature：-5c, -10, -15c, -20c, -25c, -30c, -35c, -40c
- Transport Package：Wooden Case or Plywood
- Origin：China
- HS Code：9031809090
- Production Capacity：200PCS,Month
Description
Basic Info.
Model NO. GD-H1089 Applicable Standards GB/T6538, ASTM D2602, D5293 Refrigeration Method Semiconductor Refrigeration Circulation Mode Cooling Water Circulation Temperature Control Mode Pid Temperature Controller Test Temperature -5c, -10, -15c, -20c, -25c, -30c, -35c, -40c Transport Package Wooden Case or Plywood Origin China HS Code 9031809090 Production Capacity 200PCS/MonthProduct Description
ASTM D2602 D5293 Fully Automatic Cold Cranking Simulator Engine Oil Apparent Viscosity TesterIntroduction:
The Auto Automatic Cold Cranking Simulator mainly tests the low temperature dynamic viscosity index of engine oil.
The Auto Automatic Cold Cranking Simulator is fully controlled by computer. The viscosity result is automatically calculated.
The Auto Automatic Cold Cranking Simulator is currently the top CCS tester in China.
Features:
1. The Auto Engine Oil Apparent Viscosity Tester complies with ASTM D5293, GB/T 6538 standard
2. Test temperature range: -5 to -40ºC
3. Viscosity range: 1500mPa·s to 20,000mPa·s (cP)
4. Semiconductor refrigeration, green and environmentally friendly, no flammable and harmful medium.
5. Computer automatic control, self-correction.
6. 12 samples are measured at a time, eliminating the need for operators to track operations randomly.
7. Automatic calculation of viscosity to provide more accurate data and test results files.
8. The cleaning process has a heating program to ensure thorough cleaning of the viscosity tank and improve the test accuracy.
9. Test time: The test time of each sample is about 10 minutes.
10. Operating system: Windows XP/Win7/Win8/Win10 operating system, software operation is convenient, intuitive, and can be automatically controlled.
11. Instrument operation, microcomputer control, Windows operating system, full English interface.
12. Improved rotor, low torque test condition, high repeatability. Automatically generate a calibration curve that directly displays the test viscosity results.
13. All test process is fully automatic, no manual operation is required, and the test is automatically stopped and warmed up.
14. Automatically calculate instrument deviation after calibration.
Parameters:
| 1 | Applicable standards | GB/T6538, ASTM D2602, D5293 |
| 2 | Refrigeration method | semiconductor refrigeration |
| 3 | Circulation mode | cooling water circulation |
| 4 | Temperature control mode | PID temperature controller |
| 5 | Detection method | automatic test, automatic injection, automatic cleaning |
| 6 | Result processing | automatic storage and printing |
| 7 | Test temperature | -5ºC, -10ºC, -15ºC, -20ºC, -25ºC, -30ºC, -35ºC, -40ºC |
| 8 | Working power supply | AC220 V, 50Hz |
