Benchtop Temperature Humidity Testing Chamber Climate Control Machine
Dongguan Haida Equipment Co., Ltd.- Warranty：1 Year
- Type：Temperature Humidity Testing Machine
- Accuracy Grade：0.5
- Display：Digital
- Control：Touch Screen Control
- Weight：100-500Kg
Base Info
- Model NO.：HD-E702-408B40
- Power Source：AC380V
- Controller：LCD Touch Screen
- Compressor：French Taikang
- Material：SUS 304 Stainless Steel
- System：Balanced Temperature & Humidity Control System
- Temp. Range (Optional)：-40ºC ~ + 150ºC
- Humid. Range：20 ~ 98 %R. H.
- Temp. & Humid. Accuracy：0.01ºC, 0.1%R.H
- Temp. & Humid. Regularity：±0.5ºC, ± 2%R.H
- Transport Package：Strong Wooden Case
- Specification：One Set
- Trademark：Haida
- Origin：Guangdong, China
- HS Code：9032899090
- Production Capacity：50 Sets,Moth
Description
Front-mounted water supply tank, automatic water supply system
Featurers:
1.The separation of humidifier circuit from electric circuit improves safety and protects the circuit against the leakage of water supply line.
2.Available in Chinese and English LCD touch screen, easy operation and program.
3.Able to display the relative date and information of the whole operating system in running mode, graphic display. precautions, maintenance and troubleshooting appear on the screen instantly.
4.The Sirocco fan motor provides greater cyclic airflow to avoid dead corner in the chamber so as to obtain an uniform distribution of temperature and humidity.
5.The system of heating up, heating down, dehumidifying, and humidifying can be operated independently so as to reduce the cost of testing, extend the operating life of the machine and decrease the failure rate.
6.Water Supply adopts automatic watering System, Circulating water supply together with water filter.
Corresponding standard:
1,GB2423.1-2008/IEC6008-2-1-2007
2,GB/T 2423.2-2008
3,GJB150.3A-2009
4,GJB150.4A-2009
5,GB2423.22-2008
6,GBT 2424.5-2006
7,GB/T 10589-2008
8,GB/T2423.3-2008(IEC68-2-3)
Company Introduction:
