• Model NO.：QT-5402
• Transport Package：Wooden Case
• Specification：1330*730*1500mm
• Trademark：SUZHOU QIANTONG
• Origin：Jiangsu, China
• HS Code：9031809090
• Production Capacity：575 Sets

Basic Info.

Model NO. QT-5402 Transport Package Wooden Case Specification 1330*730*1500mm Trademark SUZHOU QIANTONG Origin Jiangsu, China HS Code 9031809090 Production Capacity 575 Sets

Product Description

1. Qiantong main scope of testing machinesElectronic universal material testing machine, Horizontal tension testing machine, Hydraulic universal testing machine, MFI, Charpy Impact, Izod Impact, HDT-Vicat tester, Hardness tester, Torsion tester, Metallographic series, Oven and so on. (We accept customization.)2. Product
About product
It is to measure the damage degree of the sample and the linear combustion rate and residual flame/residual burning time of the sample. Used for horizontal and vertical flammability test of plastic material parts of electrical equipment and appliances.
The casing is painted with iron (stainless steel optional) and equipped with combustible gas leakage alarm device. It is equipped with a large area of transparent observation window, digital display meter combustion, afterflame, afterburn time.The device is beautiful in appearance, easy to use and reliable in performance. Test products include: Engineering plastics and rubber materials and so on.
Meet standard
IEC60950-1,UL94, IEC60707, IEC60695-2-2, GB5169, ISO1210, En and so on.
Specifications

1. Bunsen lamp holder: internal diameter 9.5mm±0.5mm from the air inlet up to the length of about 100mm±10mm
2. Burner Angle: 0~45°(manual adjustment, with scale)
3. Foreshadowing board: standard medical cotton
4. Combustion gas: 98% methane standard gas or 37MJ/m3±1MJ/m3 natural gas or propane (gas supplied)
5. Gas flame temperature gradient:From 100ºC±2ºC to 700ºC±3ºC for 44s±2.0s or 54s±2.0s or according to the customized standard requirements (verified by the temperature calibration device)
6. Temperature calibration verification device:5.5mm, 1.76±0.01g or 9mm,10.00±0.05g standard copper head (optional)
7. Temperature calibration verification with thermocouple: Ø 0.5 mm, K type, the import type high temperature resistant insulation sheathed thermocouples (options)
8. Number of repeated combustion: 1 ~ 9999 (digital display can be preset)
9. The use of automatic ignition device, easy to test automatically
10. Chamber volume: 0.75m3(optional 1M3)
11. Overall dimensions: 1330 x 730mm x 1500mm
12. Input power: AC 220V 50HZ 5A
